Technical Specifications

FEATURES & SPECIFICATIONS
INTENDED USE
Provides general illumination in residential applications. Ideal for use in closets, foyers, hallways,
corridors, bedrooms, oces, utility work areas, stairways and more. If required for commercial ap-
plications or operation more than eight (8) hours per day, use model FMLSL.
CONSTRUCTION
Features a white acrylic diuser and is available in 12” and 15” sizes. Hidden cam-latches provide easy
diuser removal for installation and maintenance.
OPTICS
12” units produce 1400 lumens and 15” units produce 2100 lumens, both at 50,000 hours life.
ELECTRICAL
Fixture operates at 120 volts, 60 Hz. 12” Standard input = 20 watts, 70 lumens per watt.
15” Standard input = 30 watts, 70 lumens per watt.
Works with most standard incandescent dimmers (see list of approved dimmers).
INSTALLATION
All mounting hardware included.
LISTINGS
cUL Certied to US and Canadian standards and listed suitable for damp locations.
WARRANTY
5-year limited warranty. Complete warranty terms located at
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Note: Specications subject to change without notice.
Decorative Indoor
Residential LED
Low Prole Square
Flush Mount
HIGHPERFORMANCE LED
DECORATIVE INDOOR FMLSDL
Series Module/CRI Color temperature
FMLSDL 12 12” Residential LED low prole square ush mount
FMLSDL 15 15” Residential LED low prole square ush mount
148 >80
218 >80
40 4000 K
35 3500 K
1
30 3000 K
1
27 2700 K
1
ORDERING INFORMATION
For shortest lead times, congure product using bolded options.
Example: FMLSDL 12 14840
Notes
1 Minimum 90-day lead time for non-standard color
temperatures; minimum 50 order quantity.
Catalog
Number
Notes
Type
All dimensions are inches (centimeters) unless otherwise indicated.
Specications
12” 15”
Diameter: 12 (30.5) 14.75 (37.5)
Depth: 3.25 (8.3) 3.38 (8.6)
Weight: 1 lbs (.5 kg) 1.5 lbs (.7 kg)
