Technical Specifications

Catalog

Number

Notes

Type

CONTRACTOR SELECT CPX LED Page 1 of 2

CPX

™

LED

Flat Panel

The CPX is an LED edge-lit at panel offered in industry standard wattages. The cost

effective and reliable luminaire features a diffuse lens for even illumination over the

surface of the panel. It is ideal for applications such as small ofces, schools and retail.

FEATURES:

¡ Industry standard wattages

¡ Long-life LEDs maintain greater than 70% of their lumen output at 50,000 hours

¡ 0-10V dimming driver, dims to 10%

Catalog Number UPC Description Lumens Input Watts CCT CRI Voltage Pallet qty.

CPX 2X2 3200LM 35K M4 00191848338537 2x2 Flat Panel 3200 30 3500K 80 120-277V 48

CPX 2X2 3200LM 40K M4 00191848338650 2x2 Flat Panel 3200 30 4000K 80 120-277V 48

CPX 2X4 4000LM 35K M2 00191848338490 2x4 Flat Panel 4000 40 3500K 80 120-277V 24

CPX 2X4 4000LM 40K M2 00191848338506 2x4 Flat Panel 4000 40 4000K 80 120-277V 24

Accessories: Order as separate catalog number.

2X2SMKSH 2'x2' Surface Mount Troffer Kit

2X4SMKSH 2'x4' Surface Mount Troffer Kit

PS1055CP 10W constant power

DGA22 Drywall grid adapter for 2x2 recessed fixture.

DGA24 Drywall grid adapter for 2x4 recessed fixture.

Contractor Select

™

IC RATED

NOTES

1. PS1055CP remote mounted only. See Power Sentry PS1055CP_PS1555CP battery spec sheet here

and ELA-PSMK-PSMKSD-PSDMT-PSRME remote mounting enclosure spec sheet here.

PAGE 1
Catalog Number Notes Type Contractor Select™ CPX LED ™ Flat Panel The CPX is an LED edge-lit flat panel offered in industry standard wattages. The cost effective and reliable luminaire features a diffuse lens for even illumination over the surface of the panel. It is ideal for applications such as small offices, schools and retail.
PAGE 2
Specifications Dimensions INTENDED USE: The CPX Series LED is a low-glare panel featuring an external driver. This cost-effective, reliable flat panel is visually comfortable and can be recessed, or Surface Box mounted. Suitable for many applications such as schools, offices, retail, convenience stores, hospitals, healthcare facilities and other commercial spaces. Certain airborne contaminants can diminish integrity of acrylic. Click here for Acrylic Environmental Compatibility table for suitable uses.
