CLX LED Linear
Compatible RELOC® Cables for Industrial Luminaires (ordered and shipped separately)
OCS OCU
DC PT
OD
Series Wiring instructions
RRL RELOC®-ready luminaire A Hot conductor wired to position #1 (phase A)
B Hot conductor wired to position #2 (phase B)
C Hot conductor wired to position #3 (phase C)
1
ORDERING INFORMATION
Lead times will vary depending on options selected. Consult with your sales representative.
Example: RRLA
Notes
1 C, ABE, and C12S options are not used with Quick-Flex QFC,
QSFC, QPT, and QD.
2 AE and ABE commercial fixtures should disconnect the TSPL be-
fore unplugging the RRL so it does not go into discharge mode.
3 C12S option is used with the OnePass OD and 820 SSC, PT, and
DC for 0-10V/DALI applications.
RRL RELOC®-Ready Luminaire
• RRL connectors can be used with Quick-Flex®, System 820 and OnePass® systems.
• Load side of connector factory installed to luminaire.
• 4-pole mating connector with push-in terminations allows for simple installation.
• Touch-safe design on both halves meets UL/CSA requirement.
• Wiping contact design allows safe disconnect under load.
