Specification Sheet

Page 2 of 9
CLX
INDUSTRIAL: One Lithonia Way, Conyers, GA 30012 Phone: [phone] www.lithonia.com © 2017 Acuity Brands Lighting, Inc. All rights reserved. Rev. 08/18/17
CLX LED Linear
ORDERING INFORMATION
Lead times will vary depending on options selected. Consult with your sales representative.
Example: CLX L48 5000LM SEF WDL MVOLT GZ10 40K 80CRI WH
Series Length Nominal lumens
1
Performance package Louver Lens
CLX LED linear L24 24"
1,2,3
L36 36"
1,3
L48 48"
L96 96"
1500LM 1,500 lumens
2000LM 2,000 lumens
2500LM 2,500 lumens
3500LM 3,500 lumens
4500LM 4,500 lumens
5000LM 5,000 lumens
2250LM 2,250 lumens
3000LM 3,000 lumens
3750LM 3,750 lumens
5250LM 5,250 lumens
6750LM 6,750 lumens
7500LM 7,500 lumens
3000LM 3,000 lumens
4000LM 4,000 lumens
5000LM 5,000 lumens
7000LM 7,000 lumens
3
9000LM 9,000 lumens
3
10000LM 10,000 lumens
1,3
6000LM 6,000 lumens
8000LM 8,000 lumens
10000LM 10,000 lumens
14000LM 14,000 lumens
3
18000LM 18,000 lumens
3
20000LM 20,000 lumens
1,3
SEF Standard efficiency
4
HEF Premium efficiency
(Blank) Less louver
SBLW Straight blade louver, white
5
SBLMB Straight blade louver, matte black
5
SBLGV Straight blade louver, galvanized
5
SBLSKGY Straight blade louver, smoke gray
5
L/Lens Less lens
6
FDL Flat diffuse
7,8 ,9
RDL Round diffuse
7,8 ,9
WDL Wide diffuse
7,8
Distribution Voltage Driver Color temperature Coloring rendering index
(Blank) General
ND Narrow
8
WD Wide
8
AD Aisle
8
MVOLT 120-277V
120 120V
208 208V
240 240V
277 277V
347 347V
10
480 480V
10
GZ10 0 -10V dimming
12
EZ1 Dimming to 1%
13
EOHN EldoLED dimming
12,14
30K 3000 K
35K 3500 K
40K 4000 K
50K 5000 K
80CRI 80 CRI
90CRI 90 CRI
Options Finish
PS1050 Emergency battery pack, not
available with BGTD
15
BGTD Generator transfer device, not
avaialble with PS1050
15
OCS 5', 18/3 Reloc selectable One Pass
cable
16
HA HIgh ambient, for use in ambient
temperatures up to 50°C
17
OUTCTR Wiring leads pulled through back
center of fixture
OUTEND Wiring leads pulled through end
of fixture
CS1W Staight blade plug, 120V
16
CS3W NEMA twist-lock plug, 120V
16
CS7W Staight blade plug, 277V
16
CS11W NEMA twist-lock plug, 277V
16
CS25W NEMA twist-lock plug, 347V
16
CS97W NEMA twist-lock plug, 480V
16
CS93W 600V SEOOW white cord, no plug
(no voltage required)
CS6G16STOWD5D 6' white cord, 16/5, no plug,
includes low voltage dimming wires
PLR__ Plug-in wiring, see page 9 for
ordering information
PLR1LVG Plug-in wiring,low voltage
dimming
RRL__ RELOC®-ready luminaire.
See page 8 for ordering
information
SPD Surge protection device,
provides up to 6Kv protection
16
Enabled with Atrius™:
AE1CD Atrius™ enabled, platform 1,
VLC and bluetooth positioning,
digital driver
A,B
AE1BA Atrius™ enabled, platform
1,Bluetooth positioning, analog
driver
A,C
Individual controls:
MSD7 PIR integral occupancy sensor
MSDPDT7 PDT 7 dual technology integral
occupancy control
MSD7ADC PIR integral occupancy sensor
with automatic dimming
control photocell
MSDPDT7ADC PDT integral occupancy sensor
with automatic dimming
control photocell
nLight® Wired Networking:
N100 nLight® without lumen management
NES7 nLight® nES 7 PIR integral occupancy sensor
NESPDT7 nLigh® nES PDT 7 dual technology integral
occupancy control
NES7ADCX nLight® nES 7 ADCX PIR integral occupancy
sensor with automatic dimming photocell
NESPDT7ADCX nLight® nES PDT 7 dual technology integral
occupancy sensor with automatic dimming
photocell
nLight® Wireless Networking:
RES7N nLight® AIR PIR integral occupancy sensor with
automatic dimming photocell for networking
capabilities
nLight® Wireless Zone:
RES7Z nLight Air PIR integral occupancy sensor with
automatic dimming photocell for zone control
Xpoint™ Wireless:
XAD XPoint™ Wireless 0-10V relay, internal, lower
max ambient
18
XAD924 XPoint™ Wireless 0-10V relay, internal, lower max
ambient with emergency relay (UL924 compliant)
WH White
GALVW Galvanized
with white
lens end
caps
GALVB Galvanized
with black
lens end
caps
MB Matte
black
SKGYW Smoke
gray with
white lens
end caps
SKGYB Smoke
gray with
black lens
end caps
See Accessories and footnotes on next page
