CLX LED Linear
DIMENSIONS
All dimensions are in inches (centimeters) unless otherwise indicated.
Dimensions may vary with options or accessories.
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
A3518100
1/3
1/5/17
SAMPLE MUST BE APPROVED BY
LITHONIA LIGHTING ENGINEERING
PRIOR TO PRODUCTION RELEASE
INFORMATION HEREIN CONTAINED IS THE
PROPERTY OF LITHONIA LIGHTING AND IS
TO BE HELD IN COMPLETE CONFIDENCE.
REPRODUCE WITH WRITTEN CONSENT ONLY.
TITLE:
DATE:
SCALE:
SHT.
1
OF
1
2 PLACE DECIMAL 
.030
3 PLACE DECIMAL

.015
ANGLES
±
2 DEG
TOLERANCE UNLESS NOTED
MATERIAL:
ACUITY BRANDS LIGHTING, INC.
ONE LITHONIA WAY CONYERS, GEORGIA 30012 U.S.A.
www.acuitybrands.com
www.lithonia.com
A LINE ART AAF
8/10/2017
ZONE APPD REV DESCRIPTION BY DATE
CH DRV CLX 8FT
3.44
2.29
A
A
B
C
C
B
A
INTEGRATED SENSOR ADDS 4.75 INCHES TO STANDALONE FIXTURE LENGTH
HOUSING END CAP ADDS 0.236 INCHES TO FIXTURE LENGTH PER SIDE
A
A - 7/8" KNOCK OUT
B - 0.5" by 0.16" SLOT
C - 0.3" DIA HOLE
THCLX - SHIPS TWO PER ORDER,
UTILIZES A #8 HEX HEAD SCREW AND NUT
FIXTURE SITS 1.3 INCHES FROM STRUCTURE WHEN MOUNTED
CLXANGBKT - SHIPS TWO PER ORDER
HOLES TO MOUNTING STRUCTURE ARE 0.175" DIA, 2.5" APART
FIXTURE SI
TS APPROXIMATELY 3.5" FROM STRUCTURE
WHEN MOUNTED HORIZONTAL TO STRUCTURE
2.36
3.61
4.57
5.24
2.36
3.55
8.24
2.36
3.35
7.74
2.36
3.35
4.84
L96
L48
2.24 2.24
L36
2.24
2.99
2.24
L24
A B
C
A
B
C
C
C
C
C
A
A
A
A
96.47
48.47
35.68
24.32
Length
Approx
Weight
Fixtures per
pallet
Pallet Dims
L24 4 lb 100 54x46x37
L36 5 lb 80 54x46x37
L48 7.5 lb 64 54x46x37
L96 14 lb 64 98x46x37
PALLET DIMENSIONS
PHOTOMETRICS
See www.lithonia.com.
