Technical Specifications

Catalog
Number
Notes
Type
6" Finishing Trim
6H2O
WETLITE
Drop Flange
Specifications
Height: 4-3/4 (12.1)
Lamp opening: 6-1/8 (15.6)
Diameter: 7-5/8 (19.4)
All dimensions are inches (centimeters) unless otherwise indicated.
FEATURES & SPECIFICATIONS
INTENDED USE
For use with housings LC6, L7X, L7XR.
CONSTRUCTION
Antique bronze, Oil-rubbed bronze, brushed nickel and white nishes are one-piece aluminum open
reector with integral ange.
INSTALLATION
Socket to trim interface.
Trim retention is achieved by utilizing two side-mounted torsion springs on the trim and two receiving
brackets in the can, ensuring a consistently tight t with the ceiling.
LISTINGS
U.L. Listed to U.S. and Canadian safety standards.
Wet location listed when used with outdoor rated 75W PAR38 or 75W PAR30 short neck lamp.
WARRANTY
1-year limited warranty. Complete warranty terms located at
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Actual performance may dier as a result of end-user environment and application.
Note: Specications subject to change without notice.
DOWNLIGHTING 6H2O-TOR
6H2O TOR
Series Finish Mounting method
6H2O (blank) White
MW Matte white
ORB Oil-rubbed bronze
BN Brushed nickel
TOR Torsion springs
ORDERING INFORMATION
For shortest lead times, congure product using bolded options.
Example: 6H2O TOR
Housing Compatibility: Housing and trim ordered separately.
Application Source
Maximum
wattage Housing
IC
Incandescent
75 PAR38*
LC6, L7X, L7XR
75 PAR30*
(short neck)
*Outdoor rated lamp only
6-1/8" (15.6)
7-5/8" (19.4)
Lamp included
with trim
(75W PAR30)
Accessories: Order as separate catalog number.
CRT6 6" goof ring, white
