Specification Sheet

5BP5OP LED
DOWNLIGHTING: One Lithonia Way, Conyers, GA 30012 Phone: [phone] Fax: [phone] www.lithonia.com © 2013-2016 Acuity Brands Lighting, Inc. All rights reserved. Rev. 06/09/16
5" LED Module
ADDITIONAL DATA
ENERGY DATA* - 600 Lumens
CRI - 83 CRI - 93
Min. starting temp -18°C (0°F) -18°C (0°F)
Max. temp 46°C (115°F) 46°C (115°F)
EMI/RFI FCC Title 47 CFR, Part 15, Class B FCC Title 47 CFR, Part 15, Class B
Sound rating A standards A standards
Input voltage 120V 120V
Min. power factor 0.97 0.97
Input frequency 50/60 Hz 50/60 Hz
Rated wattage 10.6W 11.3W
Input power 10.6W 11.3W
Input current .09A .09A
Input current .11A .09A
*Values at non-dimming line voltage.
LIGHTING FACTS
Trim finish Lumen multiplier
Matte White 1.00 (Baseline)
Clear Diffuse 0.99
Clear Specular 0.99
Brushed Nickel 0.83
Black Baffle 0.76
Oil Rubbed Bronze 0.78
Color temperature Lumen multiplier
2700K 0.97
3000K 1.00 (Baseline)
4000K 1.08
