FEATURES & SPECIFICATIONS

INTENDED USE

Provides general illumination in residential and light commercial applications. Ideal for use with narrow

ceiling areas such as in workshops, utility rooms and corridors. If required for commercial application

or operation more than eight (8) hours per day, consult factory for available options.

CONSTRUCTION

Full wraparound with white ﬁnished steel end plates and acrylic, prismatic diﬀuser provides widespread

illumination. Diﬀuser’s lift and shift design provides for easy installation, lamp access, cleaning and superior

retention. Available in 2 lamp conﬁgurations.

Uses a residential electronic ballast (120 volt, 60Hz) for instant on, ensures no ﬂickering and quiet operation

without interfering with other home electronics.

Utilizes (2) 32W or (2) 17W linear T8 ﬂuorescent lamps (F32T8/735) for energy eﬃciency, superior color

rendering and 10,000 hour average lamp life.

Series ballast operation and sleeved leads eliminate need for channel cover.

For use with non-dimmable switches only.

LISTINGS

CUL listed to US and Canadian safety standards and suitable for damp locations. ENERGY STAR® certiﬁed.

WARRANTY

2-year limited warranty. Complete warranty terms located at

www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx

Actual performance may diﬀer as a result of end-user environment and application.

Note: Speciﬁcations subject to change without notice.

Accessories: Order as separate catalog number.

D3324/DRB2 2ft. diﬀuser

D3348/DRB4 4ft. diﬀuser

Indoor General Purpose

Wraparound

Narrow End Utility

Linear T8 Fluorescent

Notes

1 Lamps not included.

2 Use with non-dimmable switches only.

DECORATIVE INDOOR NEWU

Catalog

Number

Notes

Type

Series

1,2

Ballast/voltage

3324 2L17W (2) 17W linear T8 ﬂuorescent lamps required

3348 2L32W (2) 32W linear T8 ﬂuorescent lamps required

120 RE 120 volt residential electronic ballast

ORDERING INFORMATION

For shortest lead times, conﬁgure products using bolded options.

Example: 3348 2L32W

DIMENSIONS

Nominal

size

Lamp

conﬁguration

Model

number Number of lamps

(A) Width

inches (cm)

(B) Length

inches (cm)

inches (cm)*

(2) Lamp 3324 2L17W (2) 17W linear T8

5-1/8"

(33.0)

24-7/8" (160.4) 2-1/2" (16.1)

(2) Lamp 3348 2L32W (2) 32W linear T8

5-1/8"

(33.0)

48-7/8" (315.3) 2-1/2" (16.1)

*Extension from ceiling.

All dimensions are inches (centimeters) unless otherwise indicated.

(A)

(B)

(C)

Summary of content (2 pages)

PAGE 1
Catalog Number Notes FEATURES & SPECIFICATIONS INTENDED USE Provides general illumination in residential and light commercial applications. Ideal for use with narrow ceiling areas such as in workshops, utility rooms and corridors. If required for commercial application or operation more than eight (8) hours per day, consult factory for available options.
PAGE 2
Wraparound Utility Lighting PHOTOMETRICS TEST NO: LTL16375 LUMINAIRE CATALOG NO.: MODEL 3348 LUMINAIRE DESCRIPTION: RESIDENTIAL WRAP, 5" X 49", TWO (2) SERIES CONNECTED T8 LAMPS, NO CHANNEL COVER, BALLAST PAINTED WHITE. ACRYLIC PRISMATI DROP DIFFUSER 1.25' DEEP, CHUANSHI RESIDENTIAL ELECTRONIC BALLAST. LAMP CATALOG NO.: FO32/735/ECO LAMP DESCRIPTION: TWO 32-WATT T8 LINEAR FLUORESCENT, HORIZONTAL POSITION LUMENS PER LAMP: 2850 CANDELA DISTRIBUTION 0 22.
