Specification Sheet

Indoor Decorative
Disk
Flush Mount
URBAN COLLECTION
Circline T5 Fluorescent
FEATURES & SPECIFICATIONS
INTENDED USE
Provides general illumination in residential applications. If required for
commercial application or operation more than eight (8) hours per day,
consult factory for available options. Ideal for use in foyers, hallways,
bedrooms, offices, utility work areas, stairways and many other rooms in
the house.
ATTRIBUTES
The Disk emphasizes contemporary design to complement decors with
a modern sensibility. A polished brushed nickel concentric, low-profile
housing and a flat glass diffuser makes a subtle but bold statement. The
diffuser has a frosted white screened center that provides a wide spread
even illumination and its clear outer ring has a glowing effect when
illuminated which is complemented by a flat polished brushed nickel disk
finial. Can be wall mounted. The finial provides easy access for cleaning
and maintenance.
Includes (1) 22W or (1) 40W circline T5 3500K fluorescent lamps for energy
efficiency, superior color rendering and long life.
Standard with electronic ballast (120 volt, 60Hz) ensures no flickering and
quiet operation without interfering with other home electronics.
Use with non-dimmable switches only.
All mounting hardware included.
Available in resale packs of two only.
LISTING
CUL listed to US and Canadian safety standards and suitable for damp
locations. ENERGY STAR
®
qualified. ADA compliant..
WARRANTY
Guaranteed for two years against mechanical defects in manufacture.
(excludes lamps)
Light Concepts Indoor Decorative - Flush Mount
DEC-107
Sheet #: DISF
Catalog Number
Notes Type
Example: 11560 BNP R2
ORDERING INFORMATION
Choose the boldface catalog nomenclature that best suits your needs and write it on the appropriate line.
Order accessories and replacement parts as separate catalog numbers.
DIMENSIONS
Notes:
1. NCLUDES - (1) 22W or (1) 40W circline T5 3500K fluorescent lamps.
2. Use with non-dimmable switches only.
3. Resale packs must be ordered in increments of 2.
4. Resale packs must be ordered in increments of 6.
Ballast/Voltage
2
(blank) 120 volt residential electronic
ballasts (standard)
Other voltage and ballast
types (Consult factory)
Resale Pack
3
R2 (2) Resale packs
per carton
R2
Nominal Lamp Model Number (A) Diameter (B) Depth*
Size Configuration Number of Lamps inches (cm) inches (cm)
10-1/2" dia 11560 (1) 22W circline T5 10-1/2" (26.7) 2-1/2" (6.4)
14-1/2" dia 11562 (1) 40W circline T5 14-1/2" (36.8) 2-1/2" (12.7)
* Extension from ceiling All dimensions are in inches (centimeters)
Accessories/Replacement parts
FC22T35 22W circline T5 fluorescent 3500K lamp
4
FC40T35 40W circline T5 fluorescent 3500K lamp
4
DDISK11 11" opal glass diffuser
DDISK15 15" opal glass diffuser
(A)
(B)
Model Number
1,2
11560 10-1/2" diameter - (1) 22W circline T5 3500K
fluorescent lamps Included
11562 14-1/2" diameter - (1) 40W circline T5 3500K
fluorescent lamps Included
Options
(Consult factory)
Finish
BNP Polished Brushed Nickel
BNP
Circline T5 Fluorescent
