Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page ■NEW □UPDATE PRODUCT SPECIFICATION Brand Name： LITE-ON Product name： WIFI module Model name： WIFI module\WCBN4521R18\ROH 1187665 Model number: DRAW. EDAM. APPD.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 3 Change History Revision Change List 1.0 Preliminary 1.1 Author Date Ken Chang 2017.10.17 Update model number and Ken Chang photo 2017.11.
Hisense WIFI module\WCBN4521R18\ROH 1. Dimension Model number 1187665 Revision 1.
Hisense WIFI module\WCBN4521R18\ROH 2. The key structure and Components 2.1 Connector spec Model number 1187665 Revision 1.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 3. Functions and Test 3.1 Functions PRODUCT FEATURES Operate at 2.4GHz/5GHz band 866Mbps PHY Rate Support 2T2R Modes 20/40/80MHz Bandwidth Support USB 2.0 support for date rates up to 12Mbps full speed and 480Mbps high speed IEEE standards support: IEEE 802.11a/b/g/n and 802.11ac draft 802.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 11ac: 11.5 +/‐ 1.5dBm (HT80) 11b @ 11Mbps: <‐82dBm Receive Sensitivity 11g @ 54Mbps: <‐70dBm 11n @ MCS7: : <‐64dBm 11ac @MCS9: <‐56dBm Normal Test Condition: 25 +/‐ 2deg.C , 65 +/‐ 2% RH Temperature & Humidity Operating: ‐10 to 70 deg.C Storage: ‐40 to 85 deg.C Operating Voltage 5V ±10% I/O supply voltage Antenna Type On Board Metallic Antenna x 2 Standby mode: 40 mA TX: 2.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 8 Page of USB CONNECTOR SPEC Plating: MATTE TIN over nickel Plated RECOMMENDED OPERATION CONDITIONS Symbol Rating Min Typ Max Units VDD33 3.3V Supply Voltage 3.0 3.3 3.6 V VDD12 1.2V Supply Voltage 1.10 1.2 1.23 V Min Typ Max Units DC CHARACTERISTICS Symbol Parameter VIL Input Low Voltage - 0 0.9 V VIH Input High Voltage 2.0 3.3 3.6 V VOL Output Low Voltage 0 - 0.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 9 of 9 4. Packing drawing 5. ENVIRONMENTAL OPERATING Operating Temperature: Relative Humidity: -10 to 70 C (32 to 158 F) 5-90% (non-condensing) STORAGE Temperature: Relative Humidity: -40 to 80 C (-40 to 176 F) 5-95% (non-condensing) 6 . Environmental requirements Components used in raw materials, packaging materials, etc., must comply with Hisense Q / RSAG J15.002 chemical substances limit requirements.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 10 of 9 FCC Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 11 of 9 radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also be informed that any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. If the labelling area is small than the palm of the hand, then additional FCC part 15.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 12 of 9 IC Statement This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
Hisense WIFI module\WCBN4521R18\ROH Model number 1187665 Revision 1.1 Page 13 of 9 The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate. le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5850 MHz) doit se conformer à la limite de p.i.r.e.
