1 Product Overview
1.1 D
ESCRIPTION
WB115C/WB115C-I2S is a Bluetooth module which using CSR Chipset CSR8311-A08
(industrial version)
1.2 FEATURES
 Fully qualified Bluetooth ® v4.0 system
 Full-speed Bluetooth operation with full piconet and scatternet support
 Class II (Max +4 dBm, 2.5mW)
 High-sensitivity Bluetooth receiver
 Wideband speech
 SBC encoding
 Full-speed USB 2.0 interface
 High-speed UART port (up to 4Mbps)
 RoHS compliance
 Low Halogen compliance
1.3 GENERAL SPECIFICATIONS
Standard
Bluetooth V
4.0 LE
Bus Interface
Data: HS-UART / USB
Voice: PCM/I2S(WB115C-I2S)
Form Factor
32.25
mm x 18mm x 2.75mm
Data Rate
1 Mbps, 2Mbps and Up to 3Mbps
Frequency Range
2.402 ~ 2.480
GHz
Transmit Output Power
-3
~ +3 dBm Class 2 Device
Receive Sensitivity
< 0.1% BER at
-70 dBm
Operating Voltage
3.3V
±5% I/O supply voltage
OS supported
Windows/Linux
Antenna Type
Printed Antenna
