S�����® M����� A�����, P��� S���� S���� OWNER'S MANUAL Rev: 12.05.
TABLE OF CONTENTS Operation 3 3 5 5 6 7 7 9 Extending the Awning Adjusting Pitch Fabric Care Pull Strap Assembly Pull Strap Components Variant Code Information Awning Fabric and Roll Bar Replacement Rev: 12.05.
Operation Extending the Awning 1. Locate the locking latch (Fig. 1) (if equipped) on the drive side awning arm. Unlock the latch (Fig. 2). NOTE: This latch is optional and may be installed on one or both support arms. 2. Using the pull rod, place the "L" end of the rod on top of the cam lock (Fig. 3A) and pull down on the lock to release it (Fig. 3). Fig. 3 Fig. 1 Fig. 2 A 3. Insert the pull rod into the pull strap (Fig. 4). 4. Pull strap to chest height using the pull rod.
Retracting the Awning 1. Grasping the strap, pull slightly toward you (Fig. 7) to release pressure on the cam lock (Fig. 7A) and disengage the cam lock. 2. While holding strap in hand, walk awning toward coach until the strap is about chest height (Fig. 8). 3. Insert pull rod into the pull strap. Fig. 7 Fig. 8 A 4. Walk awning all the way in until it stops (Figs. 9 and 10). Remove pull rod from strap. 5. Locate the locking latch (Fig. 11) (if equipped) on the drive side awning arm.
Adjusting Pitch NOTE: Without manually setting pitch to the awning, the awning will pitch itself to purge excessive water pooling in one location and may dump a significant amount of water to either end of the awning without notice. 1. Pitch can be set manually by adjusting the articulating arm to tip one side of the awning to allow water runoff. 2. Extend awning to desired location. 3. Choose the side of the awning for optimum or convenient water runoff.
SOLERA® MANUAL AWNING PULL STRAP ASSEMBLY AWNINGS Idler Head Assembly Drive Head Assembly Grommet Roll Bar Center Support Assembly NOTE: Only required for Solera Awnings greater than 21' in length Gas Strut Fabric Support Arms Pull Rod Rev: 12.05.
SOLERA® MANUAL AWNING PULL STRAP COMPONENTS AWNINGS Variant Code Information The variant code on Lippert products can assist LCI customers in obtaining additional information about the product and its components. For replacement part information, locate the variant code as outlined below and call LCI customer service at 574-537-8900.
H I J L K M O N Q P R Callout White Part # Black Part # Description H 299419 Screw - # 8 - 15 X ½ PNH ZN SQ A ST I 266156 #6 X ½ ZN Screw (fastener for head covers, 6 per cover) #8 Wax Screw J 299630 K 118043 L 266148 M 266155 N 275071 O 3334291 3334301 NOTE: For 6' awnings at the idler head to connect roll bar to the shaft.
S T U S V Callout S T U V White Part # Black Part # 295742 295743 260294 266169 281152 281154 280343 260282 286576 282484 Description Support Arm Assembly (Short, 61") Support Arm Assembly (Pitched, 66 1⁄8") Support Arm Assembly (Flat, 69") Gas Strut; 26"; 124 LBS (for Short and Flat Arm assemblies) Gas Strut; 124 - 144 LBS (for Pitched Arm assemblies) Screw - #14 - 10 x 1 ½ (arms to coach) Star Washer (for Gas Strut) Awning Fabric and Roll Bar Replacement To order replacement awning fabric and roll
All information contained within may be distributed as a full document only, unless otherwise permitted by explicit consent of Lippert Components Inc. to distribute individual parts. All information contained within is subject to change without notice. New editions will be posted on www.lci1. com and can be downloaded for free. Information contained within is considered factual until made obsolete by a *NEW* revision. Please recycle all obsolete materials.
