User's Manual
2 www.LINSAYdigital.com
Dear Customer
Thank you for purchasing the newest LINSAY
Smart watch phone that integrates a perfect full
touch screen mobile phone into its fashionable
design. With the LINSAY EX-5L, you can make
phone calls, play music and health steps, etc.
Before operating this type of smart watch, please
read the instructions and suggestions carefully to
ensure the best possible performance.
FCC Class B:
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
NOTICE:
1. The changes or modifications not
expressly approved by the party responsible for
compliance coXOG YRLG WKH XVHU¶V DXWKRULW\ WR
operate the equipment.
2. Shielded interface cables and AC power
cord, if any, must be used in order to comply with
the
Emission limits.
3. The manufacture is not responsible for
any radio or TV interference caused by
unauthorized modification to the equipment. It is
the responsibilities of the user to correct such
interference.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
Accessories Introduction
y Smart Watch
y User Guide
y Data cable
y AC Charger Adaptor USB
y Earphone Optional (BUNDLE )
y 8GB LINSAY SD Card Optional (BUNDLE )
Safety Warning
y 7KHLQIRUPDWLRQLQWKLVGRFXPHQWZRQ¶WEH
modified or extended in accordance with any
notice.
y Take good care of all related accessories.
y The illustrations in this manual are for
reference only, please prevail in kind.
y Be careful not to let your phone directly
exposed under prolonged exposure to strong
sunlight which will lead it to conduct wrong
command due to battery overheating.
y Do not attempt to repair it yourself, for the
modification to the product will affect the security
of the product, and be careful of danger.
y Avoid using the watch in the following
environment: places with excessive temperature
fluctuations, places with the temperature higher
than 60eC or lower than 0eC, places with high
pressure, dust, electrostatic interference or high
humidity.
y Avoid touching with corrosive cleaning
agents and chemicals, please use a soft, dry
cloth to clean the watch.
y This product can only be operated with
specified batteries or power adapter, while
different models may result in danger and lead
this product with all relevant licenses invalid. Use
only the original accessories recommended by
the manufacturer.
y It is prohibited to use Bluetooth Watch at
the gas stations, restricted chemical plants or
near the oil depots, for the use of Bluetooth
Watch in the above environment may raise the
risk of explosion.
Warning: When you are travelling on the
airplane, please take care to place the Bluetooth
Watch in the baggage, and try not to place it in
the handbag while going through the checkpoint,
and the LINSAY is not responsible for the
damage caused by such radiation.
Instructions on batteries & handling
batteries
y Batteries are not allowed to be thrown into
the trashcan. As a consumer, you are legally
required to handle and collect the used batteries
properly.
y Note that the battery positive and negative
direction, if opposite, it may cause damage to the
device.
y It is prohibited to try to open the batteries
or throw batteries into fire.
y The liquid flowing from the batteries is very
dangerous, and one cannot touch it unless
wearing suitable gloves.
y Never place the battery in the hands of
children.
y Remove the battery from the device if you
do not use it for a long time.
Product Details
1ȽPower switch 2ȽCamera
3ȽDisplay 4ȽSpeaker
5ȽUSB port 6ȽMIC
Initial preparation for the first time
using the LINSAY watch
Be careful to disassemble your watch and
accessories, after disassembling, place the
watch screen face down, and open the back
cover of the watch, then open the card slot based
on the direction indicated, 8GB SD card in the
slot. When secure the card in place, please
correct the golden contact point of the battery,
