Owner's manual

Appendix B
Specifications
27
Wireless-N ADSL2+ Gateway
Appendix B:
Specifications
Model Number WAG160N
Standards Draft 802.11N, IEEE 802.11g,
IEEE 802.11b, IEEE 802.3u,
g.992.1 (g.dmt), g.992.2 (g.lite),
g.992.3, g.992.5, T1.413i2 Issue 2,
U-R2 for Annex B
Ports Power, DSL, Ethernet (1-4)
Buttons Reset, Wi-Fi Protected Setup
Cabling Type CAT5 UTP, RJ-45, RJ-11
LEDs Power, Wireless, Ethernet (1-4), DSL,
Internet
Antennas 2 internal
Transmit Power 17 dBm
Antenna Gain 2 dBi
Security Features Password-Protected Conguration
for Web Access
PAP and CHAP Authentication
Denial of Service (DoS) Prevention
SPI Firewall
AP Isolation
URL Filtering, and Keyword, Java,
ActiveX, Proxy, Cookie Blocking
ToD Filter (Blocks Access by Time)
VPN Passthrough for IPSec, PPTP, and
L2TP Protocols
WPA, WPA2 Personal and Enterprise
128, 64 Bits WEP with Passphrase
WEP Key Generation
SSID Broadcast Disable
Access Restriction by MAC and IP
Addresses
Environmental
Dimensions 202 x 34 x 160 mm (8.0" x 1.3" x 6.3")
Weight 362 g (12.8 oz)
Power 12VDC, 1A
Certication FCC, CE, IC-03, Wi-Fi, A-Tick,
Telepermit, IDA
Operating Temp. 0 to 40°C (32 to 104°F)
Storage Temp. -20 to 70°C (-4 to 158°F)
Operating
Humidity 10 to 85% Noncondensing
Storage Humidity 5 to 90% Noncondensing
