3-17
Linksys IP Phone Administrator Guide
Firmware Version 5.1
Chapter 3 Managing Linksys IP Phones
Configuring the Web Service
• ToneScript – A mini-script that specifies the frequency, level and cadence parameters of a call
progress tone. May contain up to 127 characters. Syntax:
• FreqScript;Z
1[;Z2]. The section Zi is similar to the Si section in a CadScript except that each
on/off segment is followed by a frequency components parameter: Zi =
Di(oni,1/offi,1/fi,1[,oni,2/offi,2/fi,2 [,oni,3/offi,3/fi,3 [,oni,4/offi,4/fi,4 [,oni,5/offi,5/fi,5
[,oni,6/offi,6/fi,6]]]]])
where fi,j = n1[+n2]+n3[+n4[+n5[+n6]]]]] and 1 < nk < 6 indicates which of the frequency
components given in the FreqScript are used in that segment; if more than one frequency
component is used in a segment, the components are summed together.
• Example 1: Normal Ring
• 60(2/4)
• Number of Cadence Sections = 1
• Cadence Section 1: Section Length = 60 s
• Number of Segments = 1
• Segment 1: On=2s, Off=4s
• Total Ring Length = 60s
• Example 2: Distinctive Ring
(short,short,short,long)
• 60(.2/.2,.2/.2,.2/.2,1/4)
• Number of Cadence Sections = 1
• Cadence Section 1: Section Length = 60s
• Number of Segments = 4
• Segment 1: On=0.2s, Off=0.2s
• Segment 2: On=0.2s, Off=0.2s
• Segment 3: On=0.2s, Off=0.2s
• Segment 4: On=1.0s, Off=4.0s
• Total Ring Length=60s
