3-2
Linksys IP Phone Administrator Guide
Firmware Version 5.1
Chapter 3 Managing Linksys IP Phones
Using the 900 Series LCD Display
Figure 3-1 SPA900 Series LCD Controls
The function of the four soft keys depends on the option appearing on the LCD display. When more than
four functions are available, a small left or right-facing triangle (menu continuation indicator) appears
at the bottom of the LCD display. This indicates that more soft key functions can be accessed by pressing
the Navigation button left or right.
Figure 3-2 summarizes the function of the other buttons on the telephone keypad.
Figure 3-2 Telephone Keypad
To access an option, press the Setup button and press the Navigation button to select the option. Then
push the left soft key beneath the Select option to select the option. To use the shortcut to an option,
press the Setup button and type the number assigned to the option. The option does not have to appear
on the LCD to use the shortcut. To select an option with a two-digit shortcut, press the second number
within two seconds of the first number.
Line status keys
Soft keys
Navigation rocker button
Menu continuation indicator
Setup
Voicemail
Microphone mute
Speaker
Headset
Volume control
Call hold
Numeric keypad
