2-9
Linksys IP Phone Administrator Guide
Firmware Version 5.1
Chapter 2 Getting Started
SPA9000 IP PBX System
Front Panel
Back Panel
SPA9000 IP PBX System
The SPA9000 IP PBX System (VoIP side), along with the SPA400, which is Internet Telephony Gateway,
provides for an analog line and voicemail.
The system provides auto attendant features for multiple extensions. Features include:
• Auto Attendant
• Shared line appearances
• Configurable call routing
• Multiple DID numbers per VoIP line
• Call hunting (sequential, round robin, random)
• Call transfer and Call forward
• Call hold and Call waiting
You can perform SPA9000 administrative tasks using an Interactive Voice Response (IVR) system or a
built-in Web Server.
Establishing Connectivity
This section describes how to connect the SPA900 Series IP phone hardware. It includes the following
topics:
• Bandwidth Requirements1, page 2-10
Feature Function
Full-color LCD display Lists device status and configuration options.
Telephone keypad Enters numeric digits for initiating a call or for entering configuration
information.
Navigation button Scrolls between display and configuration options in the LCD display.
Soft keys 1-4 Selects options on the LCD display.
Line status indicators 1-6 Displays status of each extension.
Port Function
Phone jack Connects to the handset.
Ethernet ports (2) Connects to the SPA9000 through a local switch. Use the second port
to connect to a PC or other LAN device.
Power Connects to the 5-volt power supply.
AUX RJ-11 port Connects to optional SPA932
