2-3
Linksys IP Phone Administrator Guide
Firmware Version 5.1
Chapter 2 Getting Started
Linksys 900 Series IP Phones
Front Panel and Side of Phone
Back Panel
SPA92x, SPA94x, and SPA962 Hardware Features
The SPA941, SPA942, and SPA962 provide LCD displays and other additional hardware features,
including the following:
• Four Illuminated Call Appearance Line Buttons with Tricolor LED's (six LED’s on the SPA962)
• LED Indicates Line State – Active, Idle, On-Hold, Unregistered
• Line LED Configurable to 13 Different States (See “Line Key LED Pattern” section on page 5-31).
• Dedicated Illuminated Buttons for:
• Audio Mute On/Off
• Headset On/Off
• Speakerphone On/Off
• Four Soft Key Buttons
• Four Way Rocking Directional Knob for Menu Navigation
• Voice Mail Message Waiting Indicator Light
• Voice Mail Message Retrieval Button
• Dedicated Hold Button
• Settings Button for Access to Feature, Set-up, and Configuration Menus
• Volume Control Rocking Up/Down Knob Controls Handset, Headset, Speaker, Ringer
• Standard 12-Button Dialing Pad
• High Quality Handset and Cradle
Feature Function
Message waiting light On: you have a voicemail message.
STATUS Off: make a call. On: make a call; line is shared. Flashing: shared
line on hold. On red: line in use. Flashing red: local call on hold. On
orange: phone not registered.
FLASH Press to pickup a second incoming call, transfer a call, or setup a
three-way conference call.
REDIAL Press the redial the last number called.
Port Function
Phone jack Connect to the handset.
Ethernet port Connect to the SPA9000 through a local switch.
Power Connect to the 5-volt power supply.
