5-32
Linksys IP Phone Administrator Guide
Firmware Version 5.1
Chapter 5 Linksys IP Phone Field Reference
Phone Tab
Remote Undefined LED LED pattern during the Remote Undefined state, where the shared call state is undefined
(the station is still waiting for the state information from the application server). Not
applicable if the call appearance is not shared. Leaving this entry blank indicates the
default value of c=r;p=d.
Local Seized LED LED pattern during the Local Seized state, where this station has seized the call
appearance to prepare for a new outbound call. Leaving this entry blank indicates the
default value of c=r.
Remote Seized LED LED pattern during the Remote Seized state, where the shared call appearance is seized
by another station. Not application if the call appearance is not shared. Leaving this entry
blank indicates the default value of c=r;p=d.
Local Progressing LED LED pattern during the Local Progressing state, where this station is attempting on this
call appearance an outgoing call that is in proceeding (i.e. the called number is ringing).
Leaving this entry blank indicates the default value of c=r.
Remote Progressing LED LED pattern during the Remote Progressing state, where another station is attempting on
this shared call appearance an outbound call that is progressing. Not applicable if the call
appearance is not shared. Leaving this entry blank indicates the default value of c=r;p=d.
Local Ringing LED LED pattern during the Local Ringing state, when the call appearance is ringing. Leaving
this entry blank indicates the default value of c=r;p=f.
Remote Ringing LED LED pattern during the Remote Ringing state, where the shared call appearance is in
ringing on another station. Not applicable if the call appearance is not shared. Leaving
this entry blank indicates the default value of c=r;p=d.
Local Active LED LED pattern during the Local Active state, where the call appearance is engaged in an
active call. Leaving this entry blank indicates the default value of c=r.
Remote Active LED LED pattern during the Remote Active state, where another station is engaged in an active
call on this shared call appearance. Not applicable is this call appearance is not shared.
Leaving this entry blank indicates the default value of c=r;p=d.
Local Held LED LED pattern during the Local Held state, where the call appearance is held by this station.
Leaving this entry blank indicates the default value of c=r;p=s.
Remote Held LED LED pattern during the Remote Held state, where another station has placed this call
appearance on hold. Not applicable if the call appearance is not shared. Leaving this entry
blank indicates the default value of c=4,p=s.
Register Failed LED LED pattern when the corresponding extension has failed to register with the proxy
server. Leaving this entry blank indicates the default value of c=a.
Disabled LED LED pattern when the Call Appearance is disabled (not available for any incoming or
outgoing call). Leaving this entry blank indicates the default value of c=o.
Registering LED LED Pattern when the corresponding extension is trying to register with the proxy server.
Leaving this entry blank indicates the default value of c=r;p=s.
Call Back Active LED Call Back operation is currently active on this call appearance is not shared. Leaving this
entry blank indicates the default value of c=r;p=s.
Field Description
