5-31
Linksys IP Phone Administrator Guide
Firmware Version 5.1
Chapter 5 Linksys IP Phone Field Reference
Phone Tab
Miscellaneous Line Key Settings
This section does not apply to the WIP310 wireless phone.
Line Key LED Pattern
Line key LED colors are described in “Line Key LEDs” section on page 3-22.
Note None of the following parameters apply to the SPA901.
This section does not apply to the WIP310 wireless phone.
Field Description
Extension Select an extension to be used for this line key. Choices are:
One-line phone: 1 or disabled,
Four-line phone: 1, 2, 3, 4, or disabled.
Six-line phone: 1, 2, 3, 4, 5, 6, or disabled.
Defaults to 1.
Short Name
(Not applicable to SPA901)
A short label shown on the LCD display for Line key 1/2/3/4/5/6.
Share Call Appearance
(Not applicable to SPA901)
Yes indicates that Line Key 1/2/3/4/5/6 is a shared call appearance. Otherwise this call
appearance is not shared (in other words it is private).
Defaults to no.
Field Description
SCA Line ID Mapping
Specifies the shared call appearance line ID mapping. Choose Vertical First or Horizontal
First. Each LED can hold two calls and the first call on an LED makes it light up. Horizontal
first means the second call makes the same LED flash. Vertical first means the second call
lights up the next LED.
For example, if Extension 101 is assigned to two LEDs, and Vertical First is selected, the sec-
ond call on Extension 101 lights up the second LED. The third call makes the first LED flash,
and the fourth call makes the second LED flash.
If Horizontal First is selected, the second call on Extension 101 makes the first LED flash.
The third call lights up the second LED, and the fourth call makes the second LED flash.
SCA Barge-In Enable
Enables the SCA Barge-In.
Defaults to no.
Field Description
Idle LED LED pattern during the Idle state, where the call appearance is not is in use and is
available to make a new call. Leaving this entry blank indicates the default value of c=g.
