Chapter 5 Linksys IP Phone Field Reference
Regional Tab
Vertical Service Announcement Codes
Note None of the following parameters apply to the SPA901.
• Service Annc (Annoucement) Base Number: Defaults to blank.
• Service Annc (Announcement) Extension Codes: Defaults to blank.
Outbound Call Codec Selection Codes
These codes automatically appended to the dial-plan. So no need to include them in dial-plan (although
no harm to do so either).
Feature Dial Services Codes These codes tell the Linksys IP phone what to do when the user is listening to the first or
second dial tone.
One or more *code can be configured into this parameter, such as *72, or
*72|*74|*67|*82, etc. Max total length is 79 chars. This parameter applies when the user
has a dial tone (first or second dial tone). Enter *code (and the following target number
according to current dial plan) entered at the dial tone triggers the Linksys IP phone to
call the target number prepended by the *code. For example, after user dials *72, the
Linksys IP phone plays a prompt tone awaiting the user to enter a valid target number.
When a complete number is entered, the Linksys IP phone sends a INVITE to
*72<target_number> as in a normal call. This feature allows the proxy to process features
like call forward (*72) or BLock Caller ID (*67).
The *codes should not conflict with any of the other vertical service codes internally
processed by the Linksys IP phone. You can empty the corresponding *code that you do
not want to Linksys IP phone to process.
You can add a parameter to each *code in Features Dial Services Codes to indicate what
tone to play after the *code is entered, such as *72‘c‘|*67‘p‘. Below are a list of allowed
tone parameters (note the use of back quotes surrounding the parameter w/o spaces)
• ‘c‘ = <Cfwd Dial Tone>
• ‘d‘ = <Dial Tone>
• ‘m‘ = <MWI Dial Tone>
• ‘o‘ = <Outside Dial Tone>
• ‘p‘ = <Prompt Dial Tone>
• ‘s‘ = <Second Dial Tone>
• ‘x‘ = No tones are place, x is any digit not used above
If no tone parameter is specified, the Linksys IP phone plays Prompt tone by default.
If the *code is not to be followed by a phone number, such as *73 to cancel call
forwarding, do not include it in this parameter. In that case, simple add that *code in the
dial plan and the Linksys IP phone send INVITE *73@..... as usual when user dials *73.
Field Description
