5-3
Linksys IP Phone Administrator Guide
Firmware Version 5.1
Chapter 5 Linksys IP Phone Field Reference
Info Tab
Phone Status
Ext 1/2/3/4/5/6 Status
)
Field Description
Current Time Current date and time of the system; for example, 10/3/2003 16:43:00.
Elapsed Time Total time elapsed since the last reboot of the system; for example, 25 days and 18:12:36.
Broadcast Pkts Sent Total number of broadcast packets sent.
Broadcast Bytes Sent Total number of broadcast packets received.
Broadcast Pkts Recv Total number of broadcast bytes sent.
Broadcast Bytes Recv Total number of broadcast bytes received and processed.
Broadcast Pkts Dropped Total number of broadcast packets received but not processed.
Broadcast Bytes Dropped Total number of broadcast bytes received but not processed.
RTP Packets Sent Total number of RTP packets sent (including redundant packets).
RTP Bytes Sent Total number of RTP packets received (including redundant packets).
RTP Packets Recv Total number of RTP bytes sent.
RTP Bytes Recv Total number of RTP bytes received.
SIP Messages Sent Total number of SIP messages sent (including retransmissions).
SIP Bytes Sent Total number of SIP messages received (including retransmissions).
SIP Messages Recv Total number of bytes of SIP messages sent (including retransmissions).
SIP Bytes Recv Total number of bytes of SIP messages received (including retransmissions).
External IP External IP address used for NAT mapping.
Operational VLAN ID
(not applicable to SPA901)
ID of the VLAN currently in use.
Field Description
Registration State Shows “Registered” if the phone is registered, “Not Registered” if the phone is not
registered.
Last Registration At Last date and time the line was registered.
