CHAPTER 1 Quick Start Guide
Linksys
1
CHAPTER 1 Quick Start Guide
Package Contents
• LinksysWirelessAccessPoint
• QuickStartGuide
• EthernetCable
• ACPowerAdapter
• CDwithDocumentation
• MountingBracket
• MountingKit
• CeilingMountBackPlate
• DrillingLayoutTemplate
Physical Details
There is one LED for the device.
LED
LED Color Activity Status
Green Blinking System is booting.
Solid System is normal; no wireless device
connected.
Blue Blinking Software upgrade in process.
Solid System is normal; at least one wireless
device connected.
Red Solid Booting process or update failed; hard
reset or service required.
Port and Button
Power Port - Connect the AC power adapter to this port.
NOTE: Use only the adapter that came with your access point.
Ethernet Port - Connect a wired network device to this port. This port supports
PoE (Power over Ethernet) with a PoE switch or PoE injector. LAPAC1750 can be
powered on from an 802.3at(PoE+) compliance source.
NOTE: When both PoE and AC power adapter are connected to access point,
device will get power from PoE as higher precedence.
Using Cat5e or better cable is highly recommended.
Reset Button - Press and hold this button for less than 15 seconds to power
cycle device. Press and hold for longer than 15 seconds to reset the device to
factory default settings.
