Chapter 4 Access Point Management
Linksys
Ping Test
Ping Test is used to determine the accessibility of a host on the network.
Figure 42: Ping Test Screen
Data - Ping Test Screen
General
IP Type Enter the IP type of destination address.
IP or URL Address Enter the IP address or domain name that you want
to ping.
Packet Size Enter the size of the packet.
Times to Ping Select the desired number from the drop-list.
• 5
• 10
• 15
• Unlimited
Packet Capture
Packet Capture is used to capture and store 802.3 packets received and
transmitted by the access point based on one specified network interface. The
network interface can be radio, SSID or LAN.
Figure 43: Packet Size Screen
Data - Packet Size Screen
Network Interface Select the desired network interface from the drop-
down list. The interface can be Wireless Radio, SSID or
Ethernet.
Start Capture Click to start the capture. You will be asked to specify a
local file to store the packets.
Stop Capture Click to stop the capture.
