Chapter 3 Operation and Status
Linksys
27
Chapter 3 Operation and Status
Operation
You may need to perform the following operations on a regular basis.
• If using the Access Control feature, update the Trusted AP database as
required. (See Access Control in Chapter 2 for details.)
• Ifusing802.1xmode,updatetheUserLogindataontheWindows2000
Server, and configure the client PCs, as required.
System Summary
Provides system status of the access point.
Figure 32: System Summary Screen
Data - System Summary Screen
System Summary
Device SKU The SKU is often used to identify device model
number and region.
Firmware Version The version of the firmware currently installed.
Firmware Checksum The checksum of the firmware running in the
access point.
Hardware Version The version of the hardware.
Local MAC Address The MAC (physical) address of the wireless
access point.
Serial Number The serial number of the device.
Host Name The host name assigned to the access point.
System Up Time How long the system has been running since the
last restart or reboot.
System Time The current date and time.
Power Source The power source of the access point. It can be
Power over Ethernet (PoE) or Power Adapter.
When two power sources are plugged in, PoE
has higher precedence.
Buttons
Refresh Click to update the data on the screen.
