User manual

CHAPTER 2 Access Point Setup
Linksys
17
Data - WPA2-Enterprise Screen
WPA2-Enterprise
Primary Server Enter the IP address of the RADIUS Server on your
network.
Primary Server Port Enter the port number used for connections to the
RADIUS Server. It is a value from 1 to 65534, and
default is 1812.
Primary Shared Secret Enter the key value to match the RADIUS Server. It
consists of 1 to 64 characters.
Backup Server The Backup Authentication Server will be used
when the Primary Authentication Server is not
available.
Backup Server Port Enter the port number used for connections to the
Backup RADIUS Server. It’s a value from 1 to 65534,
and default is 1812.
Backup Shared Secret Enter the key value to match the Backup RADIUS
Server. It consists of 1 to 64 characters.
WPA Algorithm The encryption method is AES.
Key Renewal Timeout Specify the value of Group Key Renewal. It is a value
from 600 to 36000, and default is 3600 seconds.
WPA automatically changes secret keys after a
certain period of time. The group key interval
is the period of time in between automatic
changes of the group key, which all devices on
the network share.
Constantly keying the group key protects your
network against intrusion, as the would-be intruder
must cope with an ever-changing secret key.
Security Settings - WPA/WPA2-Enterprise
WPA/WPA2-Enterprise requires a RADIUS Server on your LAN to provide the
client authen-tication. Data transmissions are encrypted using WPA2 standard.
Figure 22: WPA/WPA2-Enterprise Wireless Security Screen
