User manual

CHAPTER 2 Access Point Setup
Linksys
16
Security Settings - WPA/WPA2-Personal
This method, sometimes called Mixed Mode, allows clients to use either WPA-
Personal or WPA2-Personal.
Figure 20: WPA/WPA2-Personal Wireless Security Screen
Data - WPA/WPA2-Personal Screen
WPA/WPA2-Personal
WPA Algorithm The encryption method is TKIP or AES.
Pre-shared Key Enter the key value. It is 8 to 63 ASCII characters or
64 HEX characters. Other wireless stations must
use the same key.
Key Renewal Specify the value of Group Key Renewal. It’s a value
from 600 to 36000, and default is 3600 seconds .
WPA automatically changes secret keys after a certain
period of time. The group key interval is the period
of time in between automatic changes of the group
key, which all devices on the network share.
Constantly keying the group key protects your
network against intrusion, as the would-be intruder
must cope with an ever-changing secret key.
Security Settings - WPA2-Enterprise
This version of WPA2-Enterprise requires a RADIUS Server on your LAN to
provide the client authentication. Data transmissions are encrypted using the
WPA2 standard.
Figure 21: WPA2-Enterprise Wireless Security Screen
