CHAPTER 2 Access Point Setup
Linksys
14
Security Settings
Use this screen to configure security settings of SSIDs to provide data protection
over the wireless network.
Figure 17: Security Settings
Data - Wireless Basic Settings Screen
Security
Select SSID Select the desired SSID from the drop-down list.
Security Mode Select the desired security method from the list.
Security Settings
• Disabled - No security. Anyone using the correct SSID can connect to
your network.
• WEP - The 802.11b standard. Data is encrypted before transmission, but
the encryption system is not very strong.
• WPA2-Personal - This is a further development of WPA-PSK, and offers even
greater security, using the AES (Advanced Encryption Standard) method.
This method, sometimes called Mixed Mode, allows clients to use either
WPA-Personal (with TKIP) or WPA2-Personal (with AES).
• WPA2-Enterprise - Requires a RADIUS Server on your LAN to provide the
client authentication according to the 802.1x standard. Data transmissions
are encrypted using the WPA2 standard.
If this option is selected:
• This access point must have a client login on the RADIUS Server.
• Each user must authenticate on the RADIUS Server. This is usually
done using digital certificates.
• Each user’s wireless client must support 802.1x and provide the
RADIUS authentication data when required.
• All data transmission is encrypted using the WPA2 standard. Keys
are automatically generated, so no key input is required.
• RADIUS - RADIUS mode utilizes RADIUS server for authentication and
dynamic WEP key generation for data encryption.
