relaTeD parTs
Typical applicaTion
PART NUMBER DESCRIPTION COMMENTS
LTC1473/
LTC1473L
Dual PowerPath
TM
Switch Driver N-Channel, 4.75V to 30V/3.3V to 10V, SSOP-16 Package
LTC1479 PowerPath Controller for Dual Battery Systems Three N-Channel Drivers, 6V to 28V, SSOP-36 Package
LTC4352 Low Voltage Ideal Diode Controller with Monitoring N-Channel, 0V to 18V, UV, OV, MSOP-12 and DFN-12 Packages
LTC4353 Dual Low Voltage Ideal Diode Controller Dual N-Channel, 0V to 18V, MSOP-16 and DFN-16 Packages
LTC4354 Negative Voltage Diode-OR Controller and Monitor Dual N-Channel, −4.5V to −80V, SO-8 and DFN-8 Packages
LTC4355 Positive High Voltage Ideal Diode-OR with Supply and
Fuse Monitors
Dual N-Channel, 9V to 80V, SO-16 and DFN-14 Packages
LTC4357 Positive High Voltage Ideal Diode Controller N-Channel, 9V to 80V, MSOP-8 and DFN-6 Packages
LTC4358 5A Ideal Diode Internal N-Channel, 9V to 26.5V, TSSOP-16 and DFN-14 Packages
LTC4411 2.6A Low Loss Ideal Diode in ThinSOT
TM
Internal P-Channel, 2.6V to 5.5V, 40μA I
Q
, SOT-23 Package
LTC4412/
LTC4412HV
Low Loss PowerPath Controller in ThinSOT P-Channel, 2.5V to 28V/36V, 11μA I
Q
, SOT-23 Package
LTC4413/
LTC4413-1
Dual 2.6A, 2.5V to 5.5V, Ideal Diodes in DFN-10 Dual Internal P-Channel, 2.5V to 5.5V, DFN-10 Package
LTC4414 36V Low Loss PowerPath Controller for Large
P-Channel MOSFET
s
P-Channel, 3V to 36V, 30μA I
Q
, MSOP-8 Package
LTC4415 Dual 4A Ideal Diodes with Adjustable Current Limit Dual P-Channel 50mΩ Ideal Diodes, 1.7V to 5.5V, 15mV Forward
Drop, MSOP-16 and DFN-16 Packages
LTC4416/
LTC4416-1
36V Low Loss Dual PowerPath Controller for Large
P-Channel MOSFETs
Dual P-Channel, 3.6V to 36V, 70μA I
Q
, MSOP-10 Package
1.2V Load Share
SUM85N03-06P
SUM85N03-06P
39nF
GATE1CPO1
CPO2
GND
EN1
EN2
RANGE
4370 TA04
V
INA
1.2V
V
INB
1.2V
0.1µF
7.5k
5V
OUT
39nF
V
IN1
V
CC
FETON1
COMP
FETON2
OUT1
OUT2
GATE2V
IN2
LTC4370
2mΩ
2mΩ
0.18µF
