LTC4370
16
4370f
Typical applicaTions
Current Sharing 3.3V Supplies for 20A Output
C2
0.1µF
C1
0.1µF
GATE1CPO1
CPO2
GND
EN1
EN2
RANGE
4370 TA02
V
INA
3.3V ±3%
V
INB
3.3V ±3%
R3
20k
OUT
20A
V
IN1
V
CC
FETON1
COMP
FETON2
OUT1
OUT2
GATE2V
IN2
LTC4370
R1
2mΩ
R2
2mΩ
C
C
0.47µF
C
VCC
0.1µF
M2
IRLS3034PBF
M1
IRLS3034PBF
