4. Preset Select Footswitches - 4 presets are stored within each
preset bank in the AMPLIFi FX100 internal memory: Presets A, B,
C and D. A preset stores all of the amp and eects parameters that
dene the characteristics of the tone.
To Load a Preset: Press one of the four Preset Select Footswitches
(A-D) to load the preset associated with the footswitch. The red LED
around the footswitch will indicate your current selection.
To Save a Preset: Press and hold the footswitch that indicates
your current selection to enter save mode. Footswitches A-D will
begin ashing; the next footswitch press will save the preset to that
location. Note that you are able to save presets to any bank while
in save mode. (See bank changing instructions in the next section.)
NOTE: Preset saving on the AMPLIFi FX100 is temporarily
disabled whenever there is an active Bluetooth connection with an
iOS or Android device with the AMPLIFi Remote app in use.
5. Preset Bank Display - AMPLIFi FX100 contains 25 preset banks.
The Preset Bank Indicator shows the currently loaded preset bank,
as a number (1-25).
To Change Preset Banks: Changing preset banks requires that
you select a bank, then load or save a preset within that bank. You
can select preset banks by pressing Preset Select Footswitches as
follows:
• To Increment Through Banks: Press Preset Select Footswitches
A and B simultaneously.
• To Decrement Through Banks: Press Preset Select Footswitches
C and D simultaneously.
Once you have selected the desired bank, you can load or save
a preset within the bank by pressing the desired Preset Select
Footswitch.
Preset Status Indicator - If you have changed any amp or eects
settings that are part of the preset, a red dot will appear in the bottom
right of the Preset Bank Display. The dot will disappear after the
preset has been saved or after a new preset has been loaded.
6. TAP Tempo Button - Pressing the TA P Tempo button a few times
sets the tempo of delays and other FX that sync to tempo.
Tuner Mode - Press and hold the TAP button for a few seconds to
enter Tuner Mode. When you play a note on your guitar, the pedal
will detect the closest pitch and display its value in the Bank Display.
The red LEDs on the left side of the Master Volume LED Ring will light
up when your note is at, and the red LEDs on right side will light up
when it is sharp. When the top center LED is lit, your note is in tune.
Touch any footswitch or knob to exit Tuner Mode.
FLA
T
-5
-1
0+
10
-20
-30
-50
+20
+30
+50
+5
IN TUNE
SHAR
P
IN TUNE
Tuner LED Indicators
7. Expression Pedal - The LEDs to the left of the Expression Pedal
indicate when the Expression Pedal is engaged and active. The
pedal can toggle between Volume and Wah control via the pedal’s
integrated toe switch.
To toggle the Expression Pedal: Press the Expression Pedal all the
way forward to toggle the toe switch that lies under the top of the
pedal. Pressing the toe switch will toggle between Volume and Wah
control.
