User manual

57
8. Video Modes & User Permissions
Video Modes supported
The table below lists the video modes that the IP ACCESS KVM SWITCH CLASSIC supports.
Please do not use any other custom video settings; the IP ACCESS KVM SWITCH CLASSIC
may not be able to detect them.
Resolution (x, y) Refresh Rates (Hz)
640 x 350 70, 85
640 x 400 56, 70, 85
640 x 480 60, 67, 72, 75, 85, 90, 100, 120
720 x 400 70, 85
800 x 600 56, 60, 70, 72, 75, 85, 90, 100
832 x 624 75
1024 x 768 60, 70, 72, 75, 85, 90, 100
1152 x 864 75
1152 x 870 75
1152 x 900 66
1280 x 960 60
1280 x 1024 60, 75
1600 x 1200 60 (moving 1280x1024 window)
User Role Permissions
The table below lists the user role permissions granted for three user role groups: “Superuser”,
“Administrator” and “User”
Function User Administrator Superuser
Remote Control: KVM
x x x
Remote Control: Remote Power
- x x
Remote Control: Telnet Console
x x x
Virtual Media
x x x
User Management: Change
Password
x x x
User Management: Users
- - x
KVM Settings: User Console x (w/o Misc. Settings)
x x
KVM Settings: Keyboard/Mouse
- x x
KVM Settings: Video
- x x
Device Settings
- - x
Maintenance: Device
Information
x x x
Maintenance: Event Log
- - x
Maintenance: Update Firmware
- - x
Maintenance: Unit Reset Keyboard/ Mouse,
Video
Keyboard/ Mouse,
Video
Keyboard/ Mouse,
Video, Device
58
9. Technical Specifications
Model No. IP Access KVM Switch Classic
Target Device Connection 1 x Keyboard PS/2 Mini Din 6 Pin
1 x Mouse PS/2 Mini Din 6 Pin
1 x VGA HDDB 15 Pin
1 x USB 2.0 Type B receptacle
Local Access Connection 1 x PS/2 Keyboard Mini Din 6 Pin
1 x PS/2 Mouse Mini Din 6 Pin
1 x VGA HDDB 15 Pin
Remote Access Connection 1 x RJ-45
Network Connection 10/100 Ethernet, telephone line (modem needed)
Firmware Upgrade Port 1 x Serial DB9 Pin
Max. Video Resolution Local- 1600 x 1200
Remote- 1280 x 1024
OS Compatibility MS Windows family, Unix, Sum Solaris, Linux, Mac
OSX
Browser Compatibility IE 6.0, Netscape 7.0, Mozilla 1.6 (or above)
IP Setting DHCP, Bootp, Fixed IP (DDNS supported)
Management Interface Web, Utility, Telnet, Serial port
Event Log NFS, SMTP, SNMP trap
Housing Material Metal
Power adaptor Dual input- 5V/2.6A x 2 (Redundancy)
Operating Temperature
0-50

Storage Temperature
-20 – 60

Weight 0.7 kg , incl. accessories and packaging 2.2 kg
Size (mm) 192 (L) X 120 (W) X 44 (H)
Bandwidth Consumption
The preconfigured network speed selection simply results in a different Compression and Color
Depth configuration in order to match the different bandwidth limitations of the network type
(UMTS, ISDN, etc.)
The following suggested network bandwidth planning table for IP-KVM installation is from the
test results with 3D-Labyrinth screen saver at Resolution 800x600, the worst case consuming
the highest network bandwidth.
Compression Colour
Depth
Used Bandwidth Comment
Video Optimized Video Optimized 8 bit 3.0 - 3.3 MB/s uncompressed, synchronized video data, most
bandwidth needed
Video Optimized
(high colour)
Video Optimized 16 bit 4.3 - 5.0 MB/s uncompressed, synchronized video data, most
bandwidth needed
LAN (high colour) 0 ( no compression ) 16 bit 1.0 - 1.3 MB/s uncompressed video data
LAN 0 ( no compression ) 8 bit 500 - 700 kb/s uncompressed video data
DSL 2 8 bit 110 - 140 kb/s slower video because of compression
UMTS 4 8 bit 80 - 100 kb/s slower video because of compression
ISDN 128k 6 4 bit 20 - 30 kb/s 16 colours
ISDN/Modem V.90 7 2 bit 13 - 17 kb/s gray scale
GPRS/HSCSD 8 2 bit 5 - 7 kb/s gray scale
GSM Modem 9 (best compression) 1 bit 1 - 3 kb/s Black & white video
