Instructions

Back box
This Lightwave Smart Socket requires a 50mm deep
back box in which to mount it.
Help video & further guidance
For addional guidance, and to watch a video that will
help guide you through the installaon process, please
visit the support secon on www.lightwaverf.com.
Range
Lightwave Sockets should have an excellent
communicaon range within a typical home, however,
if you encounter any range issues, try to ensure that
large metal objects or bodies of water (e.g. radiator) are
not posioned in front of the Socket or in between the
Socket and the Lightwave Link Plus.
Locking Sockets
Lightwave Smart Sockets can be locked from the
Lightwave App so that they cannot be operated
manually. This is a great way help with family safety by
ensuring that dangerous appliances cannot be turned
on or o by small children.
Automaons
Using the Link Plus and Lightwave App, you can
create custom automaons for Lightwave devices.
Automaons provide a whole host of clever features,
including mers, group acons, triggers and wireless
2-way switching. Find out more by exploring the
Lightwave App.
Installaon
This product is required to be installed by a qualied
electrician.
It is important to install this product in accordance with
these instrucons. Failure to do so may risk personal
safety, create a re hazard, violate the law and will also
void your warranty. LightwaveRF Technology Ltd will
not be held responsible for any loss or damage resulng
from not correctly following the instrucon manual.
IMPORTANT: If conducng an insulaon resistance test,
any hard-wired Lightwave devices must be disconnected
from the mains, or damage to the unit may occur.
Preparaon
A back-box with a minimum depth of 50mm
Suitable electrical screwdrivers
Knowledge of how to safely turn o/on mains
electricity
Your Link Plus, smartphone and smart socket
You will need
Faceplate
Screwdriver slot
To remove the cover plate
RF frequency:
868 MHz
Input rang:
230V~ 50Hz
Back Box Depth:
50mm min
Warranty:
2 year standard warranty
Output rang:
3700W (16A)
Standby energy use:
Less than 1W
EU Declaraon of Conformity
Product: Mains Socket (type F)
Model/Type: L41TF / L41TFWH
Manufacturer: LightwaveRF
Address: Innovaon Campus Birmingham, Faraday Wharf, Holt
Street, Birmingham, B7 4BB
This declaraon is issued under the sole responsibility of
LightwaveRF. The object of the declaraon described above is
in conformity with the relevant union harmonisaon legislaon.
Direcve 2011/65/EU ROHS,
Direcve 2014/53/EU:
(The Radio Equipment Direcve)
Conformity is shown by compliance with the applicable
requirements of the following documents:
Reference and date:
EN 301 489-1 V2.2.0 (2017/03) (EMC), EN300220-1
V3.1.1 (RF), EN300220-2 V3.1.1 (RF), EN62479:2010
(RF Exposure), IEC 60884-1: 2002 + A1: 2006 + A2: 2013 (all
relevant clauses) including German and Norwegian Naonal
Deviaons* BS EN 60669-2-1: 2004 +A12: 2010 (clauses 10,
13, 17, 19, 23, 101 & 102) used in conjuncon with respecve
clauses of BS EN 60669-1: 1999 + A2: 2008
* Meeng DIN VDE 0620-1, NEK 502
EN62321-1:2013 (RoHS)
Signed for and on behalf of:
Place of Issue: Birmingham
Date of Issue: January 2019
Name: Huw Bristow
Posion: CTO
Environmentally friendly disposal
Old electrical appliances must not be disposed of
together with residual waste, but have to be disposed
of separately. The disposal at the communal collecng
point via private persons is for free. The owner of old
appliances is responsible to bring the appliances to these
collecng points or to similar collecon points. With this
lile personal eort, you contribute to recycle valuable
raw materials and the treatment of toxic substances.
UK
1
Specicaon
On/o buon
Indicator light changes colour to
show the status of the socket
