User's Manual

9
Flexmike Controls and Connections
1. POWER/MUTE SWITCH: Press and hold to power on, press to mute, press
and hold to power o. Blue light indicates mute, white light indicates talk.
2. MIC 1 STATUS: Lighted to indicate microphone is registered as MIC 1
Solid white: Normal operation
Flashing white: Linking in progress
3. MIC 2 STATUS: When using a second microphone, this LED is lighted to
indicate microphone is registered as MIC 2 (same behavior as MIC 1 status
light above)
4. EARBUD/MIC CONNECTION: Connect the earbud for monitoring for use
with Pods only, also for use with optional EMA (earset) and LMA (lapel)
microphones.
5. CHARGING/LOW BATTERY INDICATOR: Lights red when charging, green
when fully charged. When in operation, turns red to indicate low battery.
White, normal operation.
6. MICROPHONE VOLUME UP/DOWN
7. USB INPUT: Connect audio source to send to 975.
8. LANYARD INTERFACE: \Insert the lanyard into this hook to wear the
Flexmike.
9. BATTERY: Remove the battery to replace the rechargeable battery pack
2
3
5
6
8
9
7
1
4
RIGHT SIDE
LEFT SIDE
BACK
OVERVIEW
