User's Manual

21
Daily Operation Instructions
1. AT START OF DAY, REMOVE THE MICROPHONE FROM THE CHARGER AND PUT ON
• The microphone will default to the Mute position, the status light will turn white.
• Place the microphone around your neck.
• Press the power/mute button, the light will turn blue, indicating the microphone is
active and ready to use.
• Adjust volume with the UP/DOWN buttons if necessary.
• If Flexmike needs to be powered down for some time, press and hold the power
button. To power Flexmike again, press and hold the power button until the blue
light begins to blink.
2. PRIVATE CONVERSATIONS
• Mute the Flexmike during private conversations by momentarily pressing the power
button. When muted, the blue light turns white.
• When conversation is over, momentarily press the power button again to unmute
the Flexmike.
3. END OF DAY
• Remove the Flexmike from around your neck.
• Place the Flexmike into the cradle charger and ensure the it is plugged in to an
outlet.
• The Flexmike will stay powered on during charging, but will automatically be muted.
• It is not necessary to turn o Redcat at end of day, but you may do so by pressing the
power button on the front panel.
• If you do want to power it down, it will automatically power Redcat on when
Flexmike is removed from the charging cradle
POWER/MUTE
SET-UP & USE / OPERATION
Push
Level
Tone
Input
Power
24V/1.75A
Charge
5V/500mA
Output
POWER
