TL - 3012 MEMORY CONTROL CONSOLE OWNERS MANUAL Version 0.6 02/17/2005 www.lightronics.com Lightronics Inc.
Page 2 of 6 TL-3012 MEMORY CONTROL CONSOLE OWNERS MANUAL Revision 0.6 12/17/2005 SPECIFICATIONS Channels: 12 Output connector: 3 pin XLR connector 5 pinXLR for DMX-512 Operating modes: Two Scene Manual Mode Preset Scene Playback Mode Chase Mode Compatibility: Multiplex protocol compatible with other multiplexed systems Scene memory: 24 scenes total in 2 banks of 12 each Power input: 13VAC or +15VDC Optional external power supply Chase: 12 programmable 12 step chases Dimensions: 10.
Page 3 of 6 TL-3012 MEMORY CONTROL CONSOLE Revision 0.6 OWNERS MANUAL 12/17/2005 CONTROLS AND INDICATORS MANUAL SCENE Faders: CROSS FADE: Control individual channel levels. Transfers between fader setting and stored scenes. Also used for chase fade rate control. COPY MANUAL TO MEMORY: Records fader settings to manual scene memory. Momentary Buttons: Activate associated channels at full intensity while pressed.
Page 4 of 6 TL-3012 MEMORY CONTROL CONSOLE Revision 0.6 OWNERS MANUAL 12/17/2005 OPERATING MODES The TL-3012 has 3 modes of operation: (1) Two Scene Manual Mode. (2) Preset Scene Mode. (3) Chase Mode. General operation of the unit in each mode is described below. Two Scene Manual Mode: Start by moving the “CROSS FADER” up (to the MANUAL position). The upper 12 faders will control the output channels.
Page 5 of 6 TL-3012 MEMORY CONTROL CONSOLE Revision 0.6 OWNERS MANUAL 12/17/2005 RECORDING CHASES 1 2 3 4 5 Press "RECORD". The RECORD LED will begin flashing. Press "CHASE". This causes the momentary buttons (1-12) to act as chase number selectors. Press a momentary button (1-12) to select the chase number for recording. Use the MANUAL SCENE faders to set the channel intensities for the FIRST chase step. Press "RECORD" to store the settings and advance to the next chase step.
Page 6 of 6 TL-3012 MEMORY CONTROL CONSOLE OWNERS MANUAL Revision 0.6 12/17/2005 MAINTENANCE AND REPAIR TROUBLESHOOTING Check that the multiplex cable is not defective. To simplify troubleshooting - set the unit to provide a known set of conditions. Make sure that the dimmer address switches are set to the desired channels. OWNER MAINTENANCE The best way to prolong the life of your TL-3012 is to keep it dry, cool, clean, and COVERED when not in use.
WARRANTY All Lightronics products are warranted for a period of TWO/FIVE YEARS from the date of purchase against defects in materials and workmanship. This warranty is subject to the following restrictions and conditions: A) If service is required, you may be asked to provide proof of purchase from an authorized Lightronics dealer.
Lightronics Inc.
