2.5.1 Learn The Auxiliary Siren
1. Using the Programmer, navigate to “Learn Devices”, then
“Learn Auxiliary Siren”. Registration will be enabled for 60
seconds only. The Programmer will display:
Install Siren on
Mounting Bracket
To Register
2. Install the Siren on the mounting bracket. This will set the
tamper switch and learn the siren. If successful, the
Programmer will display:
Syncronizing
Please Wait
Please Hold Test
Button for 3 Sec’s to
Complete Registration
If successful, continue to step 3.
If unsuccessful, the programmer will display:
Error: No Siren
Detected
Press ENTER
To Continue
3. Press and hold the test button on the siren for 3 seconds.
If the Auxiliary Siren fails to register within 60 seconds, the
Programmer will leave registration mode automatically. If a
system detects two registration bursts during the Auxiliary Siren
registration mode it will not register either Auxiliary Siren and
the Programmer will leave registration mode automatically.
The registration must be confirmed by pressing ENTER.
If successful the Programmer will then display:
External Siren
REGISTERED
Press ENTER
to continue
If unsuccessful, the Programmer will then display:
Siren
NOT REGISTERED
Press ENTER
to continue
If the Auxiliary Siren fails to qualify, the Programmer will return
to the “Learn Devices” menu.
4. If the Auxiliary Siren successfully qualifies, the
Programmer will display:
Assign Siren to
Siren #1?
1=YES 2=NO
5. The process may be repeated until all Auxiliary Sirens
are registered.
2.5.2 Replacing Auxiliary Siren
To replace a defective auxiliary siren:
1. Install the new Siren-strobe, use Advanced Menu |
Device | Auxiliary Siren | Choose Device | Replace
Siren to configure the new auxiliary siren the same way
the existing auxiliary siren was configured. Refer to
section 2.5.5
2.5.3 Auxiliary Siren Does Not Sound
Condition: The siren is malfunctioning.
Indications: The siren does not sound when or as it should.
Possible causes:
• No AC power to the siren.
• No battery in the siren.
• The siren was not learned into the system.
• The system is improperly programmed.
Solutions:
• Verify AC power connections to the siren. Press the test
button on the siren to verify sound and/or strobe.
• Verify that the siren is listed in the Advanced | Device |
Auxiliary Siren Menu.
• Verify that the system is programmed as follows:
o the alarm cadence is correct;
o the alarm cutoff time is correct;
• If these solutions are not effective, replace the siren.
2.5.4 Setting Options
The Siren-strobe may be configured with System Level Options
and Device Level Options.
System Level Options:
Using the programmer, enter the advanced menu and select
Global. In the Global menu, select System. There will be two
System Level Options to be configured:
Strobe Enable
Default value: No
Select Yes -- will enable the strobe for all devices on the
system.
Strobe Latching
Default value: No – the strobe stops flashing when the siren
stops sounding.
Select Yes -- the strobe continues flashing when the siren stops
sounding.
