CLASS 2
46
Connect the LED sensor to port 11 (Digital output port 10).
LED SENSOR?
Connecting to the main cell
Digital output
“S”
= White
“+”
= Red
“-”
= black
B
R
W
11 12 13 14 15 16 17 18
10
11 12 13
B
R
W
