Connecting to the main cell

Connecting the button sensor

Let’s learn how to connect the button sensor with the main cell.

Plug in the 3-pin connection jack to the button sensor.

Refer to the picture below

Digital input

“S” = White

“+” = Red

“-” = Black

※ If it’s not plugged in to the right place, the sensor won’t work. Check before you

plug it into slot 7.
