18 R 924 Litronic
Backhoe Bucket
with Straight Mono Boom 6.00 m
Operating Weight
and Ground Pressure
Operating weight includes basic machine with straight mono boom
6.00 m, stick 2.40 m, quick coupler 48 and bucket 0.95 m
3
.
Undercarriage NLC SLC
Pad width mm 500 600 750 500 600 750
Weight kg 23,550 23,800 24,400 23,650 23,900 24,500
Ground pressure kg/cm
2
0.60 0.50 0.41 0.60 0.50 0.41
Undercarriage LC WLC
Pad width mm 500 600 750 500 600 750
Weight kg 23,700 23,950 24,550 24,350 24,600 25,350
Ground pressure kg/cm
2
0.60 0.50 0.41 0.59 0.49 0.41
Digging Envelope
with Quick Coupler 1 2 3 4
Stick length m 2.40 2.70 3.00 3.70
Max. digging depth m 5.75 6.05 6.35 7.05
Max. reach at ground level m 9.90 10.20 10.45 11.10
Max. dump height m 7.50 7.70 7.90 8.25
Max. teeth height m 10.70 10.95 11.50 11.50
Digging Forces
without Quick Coupler 1 2 3 4
Digging force ISO kN 132 121 112 96
t 13.5 12.3 11.4 9.8
Breakout force kN 178 178 178 178
t 18.1 18.1 18.1 18.1
with Quick Coupler
Digging force ISO kN 125 115 107 92
t 12.7 11.7 10.9 9.4
Breakout force kN 153 153 153 153
t 15.6 15.6 15.6 15.6
Optional: heavy counterweight
(Heavy counterweight increases the operating weight by 1,000 kg and
ground pressure by 0.02 kg/cm
2
)
Buckets Machine stability per ISO 10567* (75 % of tipping capacity)
NLC-Undercarriage SLC-Undercarriage LC-Undercarriage WLC-Undercarriage
Stick length (m) Stick length (m) Stick length (m) Stick length (m)
2.40 2.70 3.00 3.70 2.40 2.70 3.00 3.70 2.40 2.70 3.00 3.70 2.40 2.70 3.00 3.70
mm m
3
kg
1,050
1)
0.95 700
1,250
1)
1.15 780
1,400
1)
1.35 860
1,500
1)
1.45 900
1,600
1)
1.55 940
1,500
1)
1.65 1,020
1,050
2)
0.95 710
1,250
2)
1.15 790
1,400
2)
1.35 870
1,500
2)
1.45 910
1,600
2)
1.55 950
1,500
2)
1.65 1,030
* Indicated loads are based on ISO 10567 max. stick length, lifted 360° on firm
1)
Standard bucket for direct mounting with teeth Z 40
2)
Standard bucket for mounting to quick coupler with teeth Z 40
Other backhoes available on request
Max. material weight
Y
= ≤ 1.8 t/m
3
,
V
= ≤ 1.5 t/m
3
,
y
= ≤ 1.2 t/m
3
,
v
= not authorized
Cutting
width
Capacity
ISO 7451
Weight
11
35
30
25
20
15
10
5
0
-5
-10
-15
-20
-25
12
mft
m0
0510152025303540
123456789101112
ft
10
9
8
7
6
5
4
3
2
1
0
-1
-2
-3
-4
-5
-6
-7
-8
1
2
4
3
