Use & Care Guide

15
refrigeraTor ComparTmenT
Figure 16
IMPORTANT
The glass plate must be inserted to the back
completely, otherwise it is not possible to click
the cover into place correctly.
Figure 15
Figure 17
Interior Light
This turns off automatically after the door has been
openedforapproximately15minutes.
If it does not turn on when the door is opened
briefly, but the temperature display is working, the
lamp(s) may be defective.
The light is located behind the cover located at the
top of the refrigerator compartment and has two
lamps.
IMPORTANT
Only original LED lamps from the appliance
manufacturer may be used.
The lamp can be purchased from the
customer service department or specialist
dealers.
WARNING!
WhenusingLEDlampsmadeby
other manufacturers, there is a risk of
overheating or fire.
Replacing the lamp:
WARNING!
To prevent possible injury due to an elec-
trical shock, be sure to disconnect the
power cord or turn off the circuit breaker
before replacing the lamp(s).
CAUTION!
To prevent possible injury due to broken
glass, use hand protection when replacing
the lamp(s).
2. Remove the glass
plate - Fig. 16.
1. Unlatch carefully the
cover at left, middle
and right using a
screwdriver - Fig. 15.
Remove the cover.
3. Remove the defective
lamp. Make sure the seal
(Fig. 17) is placed on the
new lamp before installing
it.
4. Install glass plate and
cover.
