Use and Care Manual For NoFrost combined refrigerator-freezers CS 1640 7084 357-00
Table of Contents Additional Benefits Contents • • • • Safety...................................................................... 3 Disposal of old appliance.................................. 3 Disposal of carton............................................. 3 Important safety information............................. 4 Electrical safety................................................. 4 Safety regulations............................................. 5 Unit dimensions..................................
Safety Please read and follow these instructions Disposal of Old Appliance DANGER! These instructions contain Warning and Caution statements. This information is important for safe and efficient installation and operation. Risk of child entrapment. Before you discard your old refrigerator or freezer: Always read and follow all Warning and Caution statements! • Be sure to follow your local requirements for disposal of appliances. Discarded appliances can be dangerous.
Safety Important Safety Information • To prevent injury to you or damage to the unit, the appliance should be unpacked and set up by two people. • If the appliance is damaged on delivery, contact the supplier immediately before connecting to the power source. • In the event of a power outage, minimize opening the appliance door(s). Protect the food either by placing dry ice on top of the packages or using a local frozen food locker if the power failure is of a long duration.
Safety Safety Regulations The appliance complies with UL 250 / CSA C22.2 #63 and is designed to cool, freeze and store food and to make ice (if equipped). It is designed as a household appliance. The appliance is set to operate within specific ambient temperature limits according to its climate rating. These temperature limits should not be exceeded. The correct climate rating for your appliance is indicated on the model plate.
Features Description of Appliance and Equipment - Figure 1 Description of refrigerator (1) (2) (3) (4) (5) (6) (7) (8) Operating and control elements Butter and cheese compartment - Vario Box Adjustable door racks Bottle rack Adjustable shelves Water tank Vegetable drawer Model plate (behind the vegetable drawer on the left hand side) Description of freezer (9) Ice maker (in the interior of the drawer) (10) Freezer drawers (11) Information system (12) Adjustable-height feet Figure 1 6
Features Operating and Control Elements - Figure 2, Figure 3 The electronic control panel uses touch capacitance technology. Any function can be activated by a fingertip on the symbol of the operating icons.
Operation Turning the Appliance On and Off - Figure 4 Clean the appliance before turning it on for the first time. See Cleaning. Do not place frozen food in the freezer until the temperature shows at least 0°F (-18°C). The refrigerator and freezer compartments can be operated separately. 1. Turning on: Touch the Refrigerator On/Off icon Setting the Temperature - Figure 4 The appliance is pre-set for normal operation.
Operation Temperature Display - Figure 4 Audible Alarm Signal - Figure 4 In normal operation, the following settings will be displayed: • the average refrigerator temperature • the warmest frozen food temperature. The audible alarm signal helps to protect frozen food and to save energy. When starting up for the first time or when the appliance is warm, dashes will appear in the freezer temperature display, until the temperature in the freezer compartment is 32°F (0°C).
Operation SuperCool - Figure 5 Setup Mode - Figure 5 Touching the SuperCool icon switches the refrigerator compartment to maximum cooling. It is recommended particularly if you wish to cool large quantities of food, drinks, freshly baked goods or meals rapidly. In the setup mode, you can activate the following functions: • Turning on: touch the SuperCool icon briefly so the LED turns on. The refrigerator temperature will drop to its lowest value. Note The SuperCool function uses slightly more energy.
Operation = Sabbath mode This feature considers the religious requirements on Sabbath or Holidays. When the Sabbath mode is active, some functions of the electronic controls are switched off. The door can be opened and closed at any time. • The lighting remains off. • The cooling fan remains in its actual state: If it is on, it remains on; if it is off, it remains off. • There is no door alarm. • There is no temperature alarm.
Operation Setup Mode - Figure 6 = Water quantity for ice cube tray = Child lock If the produced ice cubes of the ice maker are too small, the inflowing water quantity can be adjusted. The child lock is designed to protect the appliance from being turned off accidentally. How to adjust the water quantity How to activate the child lock • Activate the setup mode by touching the SuperFrost icon for 5 seconds. • Activate the setup mode by touching the SuperFrost icon for 5 seconds.
Refrigerator Compartment Arranging Food - Figure 7 Equipment CAUTION! To avoid possible injury, only adjust an empty shelf or door rack. Do not attempt to adjust a shelf or door rack with food on it. You can rearrange the height of the shelves and door racks as required. Repositioning the door racks - Figure 8 Slide the door rack up, pull out toward you and replace in reverse order. Figure 8 Vario Box - Figure 9 The boxes can be removed and placed on the table as a single unit.
Refrigerator Compartment Repositioning the shelves - Figure 10 1. Hold the shelf underneath with your hand to avoid from tipping down backwards when removing. 2. Lift the shelf at the front. 3. Remove the shelf forward until the circular cutout of the shelf is in line with the front supports. 4. Lift the shelf up or down and replace in the desired position.
Refrigerator Compartment Interior Light This turns off automatically after the door has been opened for approximately 15 minutes. If it does not turn on when the door is opened briefly, but the temperature display is working, the lamp(s) may be defective. The light is located behind the cover located at the top of the refrigerator compartment and has two lamps. IMPORTANT Only original LED lamps from the appliance manufacturer may be used. 1.
Freezer Compartment Freezing Freezing with SuperFrost - Figure 19 Fresh food should be frozen completely and as rapidly as possible. This is provided by the SuperFrost feature and ensures that the nutritional value, appearance and flavor of the food remains intact. • Touch the SuperFrost icon briefly so the LED turns on. Information System - Figure 18 Use frozen food within the recommended period. The numbers between the symbols indicate the storage period in months for different kinds of frozen foods.
Ice Maker Freezing and Storage Safety Instructions and Warnings for the Automatic Ice Maker • Pack frozen food in standard freezer bags or reusable plastic, metal or aluminum containers. • The ice maker is designed exclusively to make ice cubes in quantities needed by a household. • Do not allow fresh food which is to be frozen to come into contact with food already frozen. Always keep packages dry in order to avoid them sticking together.
Ice Maker Filling the Water Tank Use only filtered, de-carbonated water to fill the water tank. The use of filtered, de-carbonated water ensures the supply of drinking water with top quality flavor for problem-free ice cube production. You can achieve this water quality by using a tabletop water filter available from specialist shops. IMPORTANT Do not fill with any kind of alcoholic drinks or sugary liquids. This will damage the ice maker. 1. Pull out the water tank forwards (Figure 20). Figure 20 2.
Ice Maker Ice Maker at Vacations In case of longer vacations, the ice maker tray (arrow in Figure 24) should be emptied. How to activate the Ice Maker Vacation State - Figure 25 By setting the ice maker into the vacation state, the tray will rotate down and no water remains in the tray. Be sure the drawer is completely closed (Figure 20). 1. Activate the setup mode by touching the SuperFrost icon for 5 seconds. 2. Touch the freezer compartment Down icon until appears in the freezer temperature display.
Cleaning Cleaning WARNING! • Clean the drain opening. • To prevent possible injury due to an electrical shock, be sure to disconnect the power cord or turn off the circuit breaker before cleaning the appliance. Remove deposits using a thin instrument, e. g. a cotton bud (Figure 26). • To avoid injury or damage, do not use steam cleaning equipment to clean the appliance. IMPORTANT Water will overflow into the refrigerator compartment if the drain becomes plugged.
Defrosting/Vacation Defrosting Refrigerator compartment The refrigerator compartment defrosts automatically. The water that forms on the rear wall drains into a reservoir at the back of the appliance and evaporates automatically through the compressor heat. Freezer compartment The NoFrost system automatically defrosts the freezer compartment. Any moisture will collect on the evaporator and freeze. It will periodically defrost and evaporate.
Troubleshooting If a problem occurs during operation, check whether it is due to an operating error. Please note that even during the warranty period, some repair costs may be your responsibility.
Troubleshooting Ice Maker Troubleshooting You may be able to correct the following faults yourself: Problem Possible Cause and Remedy Ice maker cannot be turned on. Is the combined refrigerator-freezer connected to the electrical outlet? Ice maker is not making any ice. - The control lamp above the ON/OFF button flashes.
Warranty LIEBHERR WARRANTY PLAN FULL TWO YEAR WARRANTY For two years from the date of original purchase, your Liebherr warranty covers all parts and labor to repair or replace any part of the product which proves to be defective in materials or workmanship. FULL FIVE YEAR WARRANTY For five years from the date of original purchase, your Liebherr warranty covers all parts and labor to repair or replace any components that prove to be defective in materials or workmanship in the sealed system.
For Service in the U.S. Liebherr Service Center Toll Free: 1-866-LIEBHER or 1-866-543-2437 Email: Service-appliances.us@liebherr.com PlusOne Solutions, Inc. 3501 Quadrangle Blvd, Suite 120 Orlando, FL 32817 For Service in Canada Liebherr Service Center Toll Free: 1-888-LIEBHER or 1-888-543-2437 www.euro-parts.
