Liebherr specialist machines for waste management
Material handling machines
Machine model
LH 22 M LH 22 C LH 24 M LH 26 M LH 30 M LH 30 C LH 35 M
Recommended equipment/grapple combination. Other versions available on request.
Equipment version
GK9 GK9 GK10 GK11 GK12 GK12 GK13
Operational weight (without grapple) kg ca. 22,700 ca. 22,200 ca. 24,100 ca. 25,850 ca. 28,800 ca. 29,850 ca. 33,300
Engine output kW / hp 100 / 136 100 / 136 105 / 143 110 / 150 129 / 175 129 / 175 129 / 175
Standard grapple type, perforated*
SG 25 B SG 25 B SG 25 B SG 25 B SG 30 B SG 30 B SG 30 B
Capacity m³ 0.55 0.55 0.75 0.75 0.85 0.85 1.00
Weight kg 990 990 1.070 1.070 1.490 1.490 1.570
* Applicable for high-density waste = approx. 0.4 t/m³ and direct mounting of attachment on end of stick
