Liebherr specialist machines for waste management The recycling industry is growing rapidly – and it is changing. In recent years, many waste disposal companies have developed from generalists to highly specialised recycling operations. This has brought with it a whole new set of challenges to be met by the machines used in the recycling industry. Liebherr acknowledges this and develops machines and equipment options for every need and application.
wheel loaders, telescopic handlers, bulldozers and crawler loaders all sort, separate and load recyclables and solid waste quickly and reliably. These materials range from glass, metal, wood and paper to agricultural waste, to name just a few.
1 Material handling machines Powerful, robust, precise and efficient – accurate descriptions of Liebherr material handlers in demanding recycling applications. As varied as the different applications and the related requirements on the machine are in the recycling sector, so versatile and reliable the Liebherr machines present themselves to this challenge.
Performance The recycling industry is highly varied. The new generation of Liebherr material handlers really are all-round talents: when feeding a conditioner or crusher, when loading and unloading trucks and containers, when sorting materials and waste products and when piling up and moving materials of any kind. The challenges are many. Liebherr has the right solutions.
Material handling machine overview Different equipment combinations with additional working space limitations for greater safety and comfort LED headlights (optional) New Liebherr cockpit for more space and comfort Broad range of Liebherr attachments for greater productivity 6 Liebherr specialist machines for waste management
Automatic central lubrication system for machine and attachments Side area monitoring (optional) Mature engine technology with exhaust gas aftertreatment Rear area monitoring Robust and compact construction Safe and ergonomic access system Different versions of cab elevation for the best possible view Reversible fan and large radiator Liebherr specialist machines for waste management 7
Material handling machines Machine model LH 22 M LH 22 C LH 24 M LH 26 M LH 30 M LH 30 C LH 35 M Recommended equipment/grapple combination. Other versions available on request. Equipment version Operational weight (without grapple) Engine output GK9 GK9 GK10 GK11 GK12 GK12 GK13 ca. 22,200 ca. 24,100 ca. 25,850 ca. 28,800 ca. 29,850 ca. 33,300 100 / 136 100 / 136 105 / 143 110 / 150 129 / 175 129 / 175 129 / 175 kg ca.
Examples of use Processing plastic waste with the LH 22 M Litronic LH 24 M Litronic loading a wood shredder LH 26 M Litronic during the loading of plastic waste Stacking pressed solid waste with the LH 22 M Litronic Liebherr specialist machines for waste management 9
2 Electric material handling machines Liebherr electric material handling machines are multi-functional. Combined with the Liebherr quick change system, the comprehensive range of working tools enables material handling machines to achieve a high degree of flexibility and diversity. The quiet electric drive system and the reliability of the hydraulic components reduce the machine‘s maintenance costs considerably.
Reliability With more than 30 years of experience in designing electric material handling equipment, Liebherr developed the new models EP 934 C, EP 944 C and EP 954 C to comply with every demand from the market. The layout of the machines was completely revised due to the components of the electric drive system, which means the unit is more than just a conversion of a conventional vehicle with diesel drive system.
Electric material handling machine overview Equipment with long reach High lifting power Low energy costs 12 Liebherr specialist machines for waste management
Fast work cycles Low noise emissions 0.
3 Wheel loaders The powerful Liebherr wheel loaders L 507 Stereo - L 580 are employed in land filling at recycling plants and in direct solid waste processing at waste disposal sites. The extensive product range and the industrial lift arm or rather the parallel linkage specially developed for recycling operations make day-to-day work easier for the driver and ensure optimal processes when loading, transporting and sorting waste.
Performance The L 514 - L 580 wheel loaders are particularly versatile and suitable for universal use as they can be supplied with industrial lift arm / parallel linkage or Z-bar linkage. The perfect machine is always available for specific tasks such as loading and compressing bulk cargo in high walking floor containers. This widens the machine’s areas of use and therefore increases its productivity.
Wheel loaders L 524 - L 580 overview Comprehensive range of special equipment for waste management (optional) LIKUFIX quick coupler (L 524 - L 542 optional) Automatic central lubrication system (optional) Industrial lift arm / parallel linkage or Z-bar linkage (optional) Tilt cylinder protection (optional) 16 Liebherr specialist machines for waste management
Windscreen guard (optional) Additional working lights, front/rear (optional) • Premium Display, Touchscreen (L524 - L542 optional / L 550 - L 580 as standard) • Liebherr control lever with mini joystick (optional) • Joystick steering or 2-in-1 steering (optional) • Radiator easy to maintain • Fluff trap for radiator (optional) • Large-mesh radiator (optional) • Reversible fan drive (optional) • Air pre-cleaner (optional) Rear area monitoring camera via Liebherr display (L524 - L542 optional / L 550 - L 5
Liebherr wheel loaders for waste management Wheel Loader Tipping load Bucket capacity Operating weight Engine output kg m3 kg kW/HP L0009 L 507Stereo 3,712 0.9 5,470 50/68 Wheel Loader Tipping load Bucket capacity Operating weight Engine output kg m3 kg kW/HP L 509Stereo 4,430 1.2 6,390 54/73 L0009 L 514Stereo 4,920 1.4 8,520 77/105 L 524 7,350 1.8 11,500 90/122 L0009 L0009 L 528 8,200 2.1 12,300 100/136 L 538 9,100 2.3 13,380 115/156 L 542 9,750 2.5 13,800 120/163 L 550 10,850 3.
Optional equipment for waste management Liebherr wheel loaders can be fitted with a wide range of options to suit specific work. This means that the machines can be used with particular flexibility for waste management. In addition the optional equipment provides greater comfort and safety for the operator. Even in the toughest conditions this means that perfect performance and results can be achieved and productivity increased.
4 Crawler Dozers Liebherr offers a broad range of options and additional features for crawler dozers. In particular at landfill sites and solid waste handling stations, Liebherr crawler dozers have proven themselves to be extremely robust, reliable and efficient machines.
Performance Trash racks specially designed for the density and properties of the material at the landfill sites are available for the different blades. They increase blade volume and at the same time give the operator a better view of the material being transported. This guarantees high pushing performance and efficient operation. Comfort Liebherr crawler dozers offer operators a spacious workspace, designed with the latest ergonomic aspects in mind.
Crawler Dozers overview Engine compartment sealing Thermal shielding for exhaust system Additional lights Reversible fan Trash rack Hydraulic cylinder protection External air supply for alternator (not shown) 22 Liebherr specialist machines for waste management
Engine air pre-filter Hydraulic oil temperature gauge Rotating beacon Fire extinguisher Seal between cab and base machine Rear ripper or counterweight Rear striker bar (not shown) Sprocket segments with recesses Final drive seal guards Protective bars on side covers Tank guard Track shoes with trapezoidal holes (not shown) Liebherr specialist machines for waste management 23
5 Crawler Loaders Liebherr crawler loaders are the ultimate all-rounders on landfill sites both small and large, and on waste handling sites. They are able to perform all work needed, either alone or together with other machines. Depending on the specific requirements, the Liebherr crawler loader can be configured with a wide array of individual optional extras. These guarantee an optimally configured machine for every operation.
Performance Crawler loaders are not just used for pushing and compressing solid waste, but also for loading, sorting, breaking and crushing the materials. In addition, they are also for all forms of earth work needed at a waste disposal site such as filling, levelling, clearing and building embankments. Whatever the situation, it excels with its high handling capacity and fast work cycles.
Crawler Loaders overview Hydraulic oil temperature gauge Protective grid for front window (not shown) Tilt cylinder guard Fuel filler guard (not shown) Lift cylinder covers Guards for lifting cylinder hydraulic lines 26 Liebherr specialist machines for waste management
Seal between cab and base machine Rotating beacon Engine air pre-cleaner Fine perforated plates Reinforced radiator guard Reversible fan Exhaust manifold insulation External air supply for alternator (not shown) Rear striker bar Track shoes with trapezoidal holes Sprocket segments with recesses Tank guard Protection rings for final drives Liebherr specialist machines for waste management 27
6 Telescopic Handlers Thanks to their design, Liebherr telesopic handlers are particularly well suited to material handling and for moving materials in tight spaces. The small turning radius makes for easy maneuvering. Outstanding stability and large lifting capacity guarantee large handling volumes in a short time.
Performance All movements of the working hydraulics as well as the travel direction can be conveniently controlled with the multifunction joystick. As a result, the left hand can always stay on the steering wheel for more safety. Depending on how far the joystick is moved, the speed of the diesel engine is automatically adjusted and with it the speed of the working hydraulics.
Telescopic Handlers Overview ROPS/FOPS cab with best all-round view rear view camera optional Multifunction joystick and Autopower function Working lights for cab and air conditioning system Low pivot point Hydrostatic travel drive Two lift cylinders Torsionally rigid, closed main frame 30 Liebherr specialist machines for waste management Reversible fan
Scraper brush Quick hitch system Sturdy telescopic boom Industrial tyres Liebherr specialist machines for waste management 31
Wide Product Range State-of-the-art Technology The Liebherr Group is one of the largest construction equipment manufacturers in the world. Liebherr’s high-value products and services enjoy a high reputation in many other fields. The wide range includes domestic appliances, aerospace and transportation systems, machine tools and maritime cranes. To provide consistent, top quality products, Liebherr attaches great importance to each product area, its components and core technologies.
