of the embedded bootloader. The bootloader software allows reprogramming the firmware
directly over the USB port when unplugging the protection jumper and is casted into only a
4KB memory space. The configuration of the mote is stored inside the processor’s
EEPROM avoiding any risks to lose relevant configuration variables when rebooting the
mote.
1.2 WASPMOTE MODELS
Depending on the XBee module it has, there are 6l Waspmote models:
Model 1 = XBee 2.4GHz series 1 (1mW) + GSM/GPRS
Model 2 = XBee 2.4GHz series 1 (100mW) + GSM/GPRS
Model 3 = XBee 2.4GHz series 2 (2mW) + GSM/GPRS
Model 4 = XBee 2.4GHz series 2 (50mW) + GSM/GPRS
Model 5 = XBee 900MHz (50mW) + GSM/GPRS
Model 6 = XBee 900MHz (100mW) + GSM/GPRS
You can find any of the modules in the delivered pack.
1.3 WASPMOTE ANTENNAS
There are three different antennas included in the Waspmote pack:
1º-XBee SMA antenna (datasheet attached)
2º-GSM/GPRS UFL antenna (datasheet attached)
3º-GPS UFL antenna (datasheet attached)
1.4 HOW TO SET THE MODULES
First of all for each module connect its antenna.
(the GPS module is soldered on the bottom of the board so you can plug its antenna from
the beginning)
As Wasp can use different modules for communicating, they can be exchanged easily, just
be careful with these:
