Custom Scan Sizes menu
Use To
Custom Scan Size [x]
Scan Size Name
Width
Height
Orientation
Portrait
Landscape
2 scans per side
Off
On
Specify a custom scan size name and page orientation.
Notes:
• The custom scan size name replaces Custom Scan Size [x] in the printer
menus.
• ADF Media Type is the factory default setting for custom scan sizes 3, 4,
5, and 6.
• 8.5 inches is the U.S. factory default setting for Width. 210 millimeters is
the international factory default setting for Width.
• 14 inches is the U.S. factory default setting for Height. 297 millimeters is
the international factory default setting for Height.
• Portrait is the factory default setting for Orientation.
• Off is the factory default setting for “2 scans per side.”
Universal Setup menu
Use To
Units of Measure
Inches
Millimeters
Identify the units of measure.
Notes:
• Inches is the US factory default setting.
• Millimeters is the international factory default setting.
Portrait Width
3–8.5 inches
76–216 mm
Set the portrait width.
Notes:
• If the width exceeds the maximum, then the printer uses the
maximum width allowed.
• 8.5 inches is the US factory default setting. You can increase the
width in 0.01‑inch increments.
• 216 mm is the international factory default setting. You can increase
the width in 1‑mm increments.
Portrait Height
3–14.17 inches
76–360 mm
Set the portrait height.
Notes:
• If the height exceeds the maximum, then the printer uses the
maximum height allowed.
• 14 inches is the US factory default setting. You can increase the
height in 0.01‑inch increments.
• 356 mm is the international factory default setting. You can increase
the height in 1‑mm increments.
Understanding the printer menus 144
