10
12
13
17
16
14
15
11
Use the To
10 Scanner glass Scan or copy photos and documents.
11 Power supply with port Connect the printer to the power cord.
12 Duplex unit
• Print on both sides of a sheet of paper.
• Clear paper jams.
13 USB port Connect the printer to a computer using a USB cable.
Warning—Potential Damage: Do not touch the USB port except when
plugging in or removing a USB cable or installation cable.
14 Printhead access area Install the printhead.
Note: The carrier moves to the printhead access area when no printhead
is installed in the printer.
15 Jam clearance cover Access and clear paper jams.
16 Ink cartridge access area Install, replace, or remove ink cartridges.
17 Scanner unit
• Access the ink cartridges and printhead.
• Clear paper jams.
Using the printer control panel
9
101112
1
34
5
67 8
2
Use To
1 Power
• Turn the printer on and off.
• Switch to Sleep mode.
Note: When the printer is on, press
to switch to Sleep mode.
Press and hold
for three seconds to turn off the printer.
2 Display
Note: The display is turned
off in Sleep mode.
View:
• Printer status
• Messages
• Menus
3 Arrow buttons Navigate through menu items that appear on the display.
4 Select
OK
• Select menu options.
• Save settings.
5 Home
Return to the home screen.
6 Color
Switch to color mode.
7 Black
Switch to black‑and‑white mode.
8 Start
Start a job, depending on which mode is selected.
About your printer 12
