CD PLAYER DUAL ALARM DIGITAL CLOCK RADIO MODEL CDR-1906 OPERATING INSTRUCTIONS • • • • • • • • DUAL ALARMS - PERFECT FOR WEEKDAYS & WEEKENDS LARGE LCD DISPLAY FOR CLOCK, RADIO & CD PLAYER PLAYS ALL MUSIC COMPACT DISCS, CD-R & CD-RW FULLY PROGRAMMABLE CD PLAYER WITH REPEAT PLAY ANALOG AM/FM TUNER WITH DIGITAL DISPLAY WAKE UP TO CD, RADIO OR BUZZER ALARM EASY TO SET CLOCK & ALARM BATTERY BACK-UP (9V BATTERY, NOT INCLUDED) PLEASE READ CAREFULLY BEFORE USE IB-CDR1906(AD-CL)-WM-E-012105 IB-CDR1906(AD-CL)-WM-
WARNING TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT SAFETY INSTRUCTIONS 15. Power Sources - This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions. 16.
1. Setting the Clock HOUR button DIMMER button MINUTE button CLOCK SET button Large display for clock, radio & CD play 1 Connect the AC power cord into a live wall outlet. If the plug of the AC power cord does not match your outlet, do not force it. Reverse it and try again. This plug is polarized and only fits one way into the wall outlet. Clock display will show “12:00 ” flashing. In cas e you want to reduce the brightness of the display when you are sleeping, you can press the DIMMER button.
2. Setting the Alarm Time This set has dual alarms. You may set ALARM 1 to wake you at a certain time, or ALARM 2 to wake you at a different time, or ALARM 1+2 - both alarms will sound at the time you set. This feature is useful for a husband & wife waking up at different time or a single person who likes to wake up at different time during weekdays and weekends. To set ALARM 1, slide the ALARM switch to position 1, the words “ALARM 1” will show in the display.
3. Playing a CD CD PLAY/PAUSE button CD STOP button Open the disc door by lifting here BUZZER/AUTO/ OFF/ON switch (on the left side) FM/AM/CD switch Connect the AC power cord (see Setting the Clock). 1 FM AUTO BUZZER AM CD OFF ON 2 in the display, then “ ”. Lift either side of the CD DOOR to open it and place a CD in the CD compartment. The label side of the CD should face upward. 3 4 Slide the FM/AM/CD FUNCTION switch to CD position and the BUZZER/AUTO/OFF/ON s wi tc h to O N pos i tion .
4. More about CD operation Use these buttons for additional operations CD PLAY/PAUSE button CD STOP button Open the disc door by lifting here SKIP/SEARCH buttons Phones jack PAUSE symbol Volume control FM/AM/CD function switch Tip When the CD play is paus ed, the display will show the ” pause symbol “ and no mus ic will play. To res ume play, pres s the PLAY/ PAUSE button again.
5. Playing CD tracks repeatedly (Repeat Play) STOP button PLAY/PAUSE button PROGRAM/REPEAT button SKIP/SEARCH buttons BUZZER/AUTO/ OFF/ON switch (on the left side) FM/AM/CD function switch 1. Slide the FM/AM/CD FUNCTION switch to CD position and the BUZZER/AUTO/ OFF/ON switch to ON position. 2. Select the track by pressing SKIP/SEARCH buttons, and then press PLAY/PAUSE button. 3. Press the CD PROGRAM/REPEAT button.
6. Playing CD in programmed or random order 1. Programmed Play You can make a program of up to 20 tracks in the order you want them to be played. STOP button PLAY/PAUSE RANDOM button button PROGRAM/REPEAT button SKIP/SEARCH buttons BUZZER/AUTO/ OFF/ON switch (on the left side) FM/AM/CD function switch 1. Slide the BUZZER/AUTO/OFF/ON switch to ON position and the FM/AM/CD FUNCTION switch to CD position. Wait until the total track number shows in the display and the CD disc is not rotating. 2.
7. Listening to the radio RIGHT SIDE VIEW LEFT SIDE VIEW ALARM switch BUZZER/AUTO/ OFF/ON switch TUNING FM/AM/CD VOLUME PHONES control switch control jack Connect the supplied AC power cord (see Setting the Clock). 1 AM FM CD AUTO ON BUZZER 2 Tune into the station you prefer using the TUNING control. Adjust for the clearest sound. The display will show you the frequency of the station tuned in. This is useful when you know the station’s frequency.
8. More about radio operation PHONES jack FM ANTENNA BATTERY COMPARTMENT (at the bottom of the set) To improve broadcast reception Fully stretch out the FM ANTENNA for better FM reception. Reorient the player itself for better AM reception. Or locate the set near a window. To listen without disturbing others Connect your headphones (optional - not included) into the PHONES jack at the right side of the set. The speakers will automatically be silenced.
9. Waking up to alarm or music NOTE:When the BUZZER/AUTO/OFF/ON switch is set to ON or OFF position, the words “ALARM 1” or “ALARM 2” will not show in the display and no alarm buzzer, CD music or radio will come out at the set alarm time. 1. Waking up to alarm 1. Set the BUZZER/AUTO/OFF/ON switch to BUZZER position. 2. Set the alarm time as previously instructed and slide the ALARM switch to ALARM 1, AL ARM 2 or ALA RM 1 +2, the prop er ALARM status will show in the display.
10. Snooze and Sleep functions When alarm or music comes on SNOOZE ALARM SLEEP/OFF 1. To sleep extra 7 minutes Just press the SNOOZE button, the alarm or music will stop and come on after 7 minutes. 2. To stop the alarm buzzer, CD music or radio J us t pres s the ALARM/SLEEP/O FF button, the alarm buzzer, CD music or radio will stop and come on next day. AUTO BUZZER OFF ON 3. To off the alarm function J ust s lide the BUZZER/AUTO/O FF/O N switc h to O FF position.
Precautions On safety On power sources • As • For battery backup, you may use a 9V the las er beam us ed in the CD player section is harmful to the eyes, do not attempt to dis as s emb le the c as ing. Refer s erv icing to qualified personnel only. battery (optional), so that you will not have to re-set the clock every time you disconnect the power. • The nameplate indic ating operating voltage, power c ons umption, etc . is located at the bottom of the set.
Precautions (continued) Cleaning the lens Notes on CDs • If the lens becomes dirty, it may cause a skipping of sound during CD operation. Clean with a commercially available lens cleaner blower or a cotton swab. Before playing, clean the CD with a cleaning cloth. Wipe the CD from the center out. not use solvents such as benzine, • Do th inne r, c omme rc i ally av a ilab le cleaners or anti-static spray intended for vinyl LPs.
Trouble Shooting Remedy Problem • Connect the AC power cord to a wall outlet The power is not on. securely. Make sure that outlet has power. • Make sure the FUNCTION switch is at the General right position as you want. • Adjust the volume. • Un plug the hea dpho nes There is no sound. when lis teni ng through speakers. • AM or PM is not set correctly. Is alarm time Alarm does not come on in the morning.
Specification GENERAL DESCRIPTION Power source: AC 120V, 60Hz, DC 9V (optional - for clock backup) Speakers: 3” 8 ohm Output power: 1.5W/channel Dimensions: Width: 6 1/2” Depth: 8 1/4” Height: 5” Weight: 3.4 LBs (without battery) CD SECTION Plays disc type: Any compact discs bearing this logo Laser wavelength: 760 - 800 NM Tracking method: 3 - spot error detection 3.86 mm lens Frequency response: 50 Hz - 15 kHz (+1/-2dB) NOTE: This CD player will play normal music CDs (or CD-R/CD-RW CDs).
