Chapter 4: Configuring the Application
SecureMind Surveillance Manager
Page 61
4.8.4 Activity Detection Settings
You can configure the Region of Interest (ROI) to detect activity on the camera. You can enable three
ROI and each region is a polygon that have six vertices. To change the ROI shape, click and drag the ROI
vertices. Also, you can move the shape by clicking inside the shape and dragging it.
Note: If you do not select any ROI, then activity for the entire camera view is detected.
To configure the ROI, perform the following:
1. Go to Settings > Add Camera.
The Choose an option to Add Camera screen is displayed.
2. In the Cameras list, click > Activity Detection Settings.
Figure 49. Activity Detection Settings
