Operation Manual

Chapter 4: Configuring the Application
SecureMind Surveillance Manager
Page 28
4. Click Add on the required camera.
The IP Camera Information screen is displayed.
 Note: The number of cameras that can be added depends on the application license.
Figure 21. IP Camera Information
5. In Camera Name, edit the camera name.
6. In Username, enter the user name of the IP camera.
7. In Password, enter the password of the IP camera.
 Note: This is the user name and password required to access the home page of the IP Camera.
8. In Advanced options, to specify HTTP, and RTSP port numbers, perform the following:
 Note: The default HTTP port number is 80, and RTSP port number is 554. Enter the HTTP,
and RTSP port specified, if other than the default port numbers.
i. HTTP Port: Enter the HTTP port number of the camera.
ii. RTSP Port: Enter the RTSP port number of the camera.
